GE af-600 fp

52
Table – 3 (575V)
Device
AF - 600 HP Rating(s)
Minimum Wire Size
Maximum Wire Size
Required Torque
Load Reactor (6KFP
Series)
1 through 5
# 22 AWG
# 10 AWG
4.5 lb. in.
7.5 through 20
# 14 AWG
# 6 AWG
16 lb. in.
25 through 40
# 18 AWG
# 4 AWG
16 lb. in.
50 through 100
# 6 AWG
1/0
45 (6 - 4AWG), 50
(2-1/0 AWG)
125
# 2 AWG
4/0
150 lb. in.
150
Note 2
Note 2
Note 1
Load Reactor (6KFP*L
Series) - 3% Z
1 through 10
# 22 AWG
# 10 AWG
4.5 lb. in.
15 through 20
# 14 AWG
# 6 AWG
16 lb. in.
25
# 18 AWG
# 4 AWG
16 lb. in.
30 through 75
# 6 AWG
# 1/0
45 (6 - 4AWG), 50
(2-1/0 AWG)
100 through 650
Note 2
Note 2
Note 1
Load Reactor (6KFP*L
Series) - 1% Z
1 through 10
# 22 AWG
# 10 AWG
4.5 lb. in.
15 through 20
# 14 AWG
# 6 AWG
16 lb. in.
25
# 22 AWG
# 14 AWG
16 lb. in.
30
# 14 AWG
# 6 AWG
16 lb. in.
40 through 75
# 6 AWG
# 1/0
45 (6 - 4AWG), 50
(2-1/0 AWG)
100 through 650
Note 2
Note 2
Note 1
Control Terminal Board
2 through 300
# 26 AWG
# 10 AWG
Note 1
Note (1): For unmentioned torques, Refer UL508A tables in tab "UL508A" in the same excel file
Note (2): The input and output terminals have Busbars provision for motor connections.
DEH40603 – Page 6 AN 12-1007 Rev 05, 04/04/2012
