GE ASH220NCDW Installation Instructions

31-5000275 Rev. 5 11
Wall Brackets
35 N
1.84in (46mm)
0.236in (6mm)
Ø 2 1/4in (57mm)
40 N
2.795in (71mm)
0.472in (12mm)
Ø 2 1/4in (57mm)
4.961in (126 mm)
1.417in (36mm)
50 N
Ø 2 1/4in (57mm)
1.417in (36mm)
4.882in (124mm)
Ø 2 1/4in (57mm)
70 N
5.906in (150mm)
1.417in (36mm)
Ø 2 1/4in (57mm)
100 N
4.961in (126mm)
1.614in (41mm)
50 T
Ø 2 1/4in (57mm)
1.614in (41mm)
4.882in (124mm)
Ø 2 1/4in (57mm)
70 T
3.150in (80mm)
1.85in (47mm)
35 T
Ø 2 1/4in (57mm)
Capacity (BTUh) Bracket Style Part Number
07K/09K/12K 35N/35T/40N WJ65X23038/WJ65X23240/WJ65X23038
15K/18K 50N/50T/70N WJ65X23251/WJ65X23251/WJ65X23056
24K 70N/70T WJ65X23056/WJ65X23056
30K/36K 100N WJ65X22785
