GE Bently Nevada 3300

3300 System Installation Manual
20
SIGNAL INPUT/QUAD RELAY CARD OPTION *
RELAY OPTIONS INSTALL REMOVE
ALERT RELAYS
NORMALLY
DE-ENERGIZED
W2,3C
W3D,4D
W3A,4C
ALERT RELAYS
NORMALLY
ENERGIZED
W3A,4C W2,3C
W3D,4D
DANGER RELAYS
NORMALLY
DE-ENERGIZED
W1,3B
W4A,4E
W4B,4F
DANGER RELAYS
NORMALLY
ENERGIZED
W4B,4F
W1,3B
W4A,4E
* For more information on relay configuration refer to
Sections 13 and 14.
