Section 3 - RACK ASSEMBLY OPTIONS
3
3. RACK ASSEMBLY OPTIONS
EXTERNAL DIMENSIONS
A B
01,11,21,31 = 4 POSITIONS 11.00 IN. (279.4 mm) 8.00 IN. (203.2 mm)
02,12,22,32 = 6 POSITIONS 15.00 IN. (381.0 mm) 12.00 IN. (304.8 mm)
03,13,23,33 = 8 POSITIONS 19.00 IN. (482.6 mm) 16.00 IN. (406.4 mm)
04,14,24,34 = 10 POSITIONS 23.00 IN. (584.2 mm) 20.00 IN (508.0 mm)
05,15,25,35 = 12 POSITIONS 27.00 IN (685.8 mm) 24.00 IN. (609.0 mm)
06,16,26,36 = 14 POSITIONS 31.00 IN. (787.4 mm) 28.00 IN. (711.2 mm)
07,17,27,37 = 8 POSITIONS 19.00 IN. (482.6 mm) 16.00 IN (406.4 mm)
