GE Multilin C60 Breaker Protection System 5-131
5 SETTINGS 5.4 SYSTEM SETUP
5
PMU 1 STYLE: This setting selects whether synchrophasors are reported in rectangular (real and imaginary) coordinates
or in polar (magnitude and angle) coordinates. This setting complies with bit-0 of the FORMAT field of the IEEE C37.118
configuration frame.
With 90-5 PMU, the FORMAT and STYLE are Floating-point and Polar respectively, as specified in the IEC 61850
standard.
IEC 61850–90–5 PMU 1 CONFIGURATION
PATH: SETTINGS SYSTEM SETUP PHASOR MEASUREMENT BASIC CONFIGURATION PMU1PMU 1 BASIC CONFIGURA-
TION 90 – 5 PMU 1 CONFIGURATION
PMU1 LDINST: A user-defined visible string (maximum 64 char ASCII test) to assign Logical Device (LD) Inst for a PMU
LD.
As per IEC 61850-6 standard specification, the PMU LD Name is the concatenated combination (to total 64 charac-
ters) of IED Name (specified in IEC 61850 Server Settings) appended with PMU X LDINST string.
90–5 PMU 1
CONFIGURATION
PMU 1 LDINST:
PMU1
Range: 64 char ASCII text
To Next Page
