Page #39 background imageLoading...
Page #39 background image
GE Multilin C60 Breaker Protection System 2-9
2 PRODUCT DESCRIPTION 2.2 ORDER CODES
2
2.2ORDER CODES 2.2.1 OVERVIEW
The C60 is available as a 19-inch rack horizontal mount or reduced-size (¾) vertical unit and consists of the following mod-
ules: power supply, CPU, CT/VT, contact input and output, transducer input and output, and inter-relay communications.
Each of these modules can be supplied in a number of configurations specified at the time of ordering. The information
required to completely specify the relay is provided in the following tables (see chapter 3 for full details of relay modules).
Order codes are subject to change without notice. See the ordering page at
http://www.gegridsolutions.com/multilin/order.htm
for the latest options.
The order code structure is dependent on the mounting option (horizontal or vertical) and the type of CT/VT modules
(enhanced diagnostic CT/VT modules or HardFiber
TM
process bus modules). The order code options are described in the
following sub-sections.
2.2.2 ORDER CODES WITH ENHANCED CT/VT MODULES
The order codes for the horizontal mount units are shown below.
Table 2–4: C60 ORDER CODES (HORIZONTAL UNITS)
C60 - * ** - * * * - F ** - H ** - M ** - P ** - U ** - W/X ** Full Size Horizontal Mount
BASE UNIT C60 | | | | | | | | | | | Base Unit
CPU T | | | | | | | | | | RS485 with 3 100Base-FX Ethernet, multimode, SFP with LC
U | | | | | | | | | | RS485 with 1 100Base-T Ethernet, SFP RJ-45 + 2 100Base-FX Ethernet, multimode, SFP with LC
V | | | | | | | | | | RS485 with 3 100Base-T Ethernet, SFP with RJ-45
SOFTWARE 00 | | | | | | | | | No Software Options
01 | | | | | | | | | Ethernet Global Data (EGD)
03 | | | | | | | | | IEC 61850
04 | | | | | | | | | Ethernet Global Data (EGD) and IEC 61850
14 | | | | | | | | | Two Phasor Measurement Units (PMUs)
15 | | | | | | | | | IEC 61850 and two PMUs
A0 | | | | | | | | | CyberSentry Lvl 1
A1 | | | | | | | | | CyberSentry Lvl 1 and Ethernet Global Data
A3 | | | | | | | | | CyberSentry Lvl 1 and IEC 61850
A4 | | | | | | | | | CyberSentry Lvl 1, Ethernet Global Data, and IEC 61850
AE | | | | | | | | | CyberSentry Lvl 1 and two PMUs
AF | | | | | | | | | CyberSentry Lvl 1, IEC 61850, and two PMUs
B0 | | | | | | | | | IEEE 1588
B1 | | | | | | | | | IEEE 1588 and Ethernet Global Data
B3 | | | | | | | | | IEEE 1588 and IEC 61850
B4 | | | | | | | | | IEEE 1588, Ethernet Global Data, and IEC 61850
BE | | | | | | | | | IEEE 1588 and two PMUs
BF | | | | | | | | | IEEE 1588, IEC 61850, and two PMUs
C0 | | | | | | | | | Parallel Redundancy Protocol (PRP)
C1 | | | | | | | | | PRP and Ethernet Global Data
C3 | | | | | | | | | PRP and IEC 61850
C4 | | | | | | | | | PRP, Ethernet Global Data, and IEC 61850
CE | | | | | | | | | PRP and two PMUs
CF | | | | | | | | | PRP, IEC 61850, and two PMUs
D0 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1
D1 | | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and Ethernet Global Data
D3 | | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and IEC 61850
D4 | | | | | | | | | IEEE 1588, CyberSentry Lvl 1, Ethernet Global Data, and IEC 61850
DE | | | | | | | | | IEEE 1588, CyberSentry Lvl 1, and two PMUs
DF | | | | | | | | | IEEE 1588, CyberSentry Lvl 1, IEC 61850, and two PMUs
E0 | | | | | | | | | IEEE 1588 and PRP
E1 | | | | | | | | | IEEE 1588, PRP, and Ethernet Global Dada
E3 | | | | | | | | | IEEE 1588, PRP, and IEC 61850
E4 | | | | | | | | | IEEE 1588, PRP, Ethernet Global Data, and IEC 61850
EE | | | | | | | | | IEEE 1588, PRP, and two PMUs
EF | | | | | | | | | IEEE 1588, PRP, IEC 61850, and two PMUs
F0 | | | | | | | | | PRP and CyberSentry Lvl1
F1 | | | | | | | | | PRP, CyberSentry Lvl1, and Ethernet Global Data
F3 | | | | | | | | | PRP, CyberSentry Lvl 1, and IEC 61850
F4 | | | | | | | | | PRP, CyberSentry Lvl 1, Ethernet Global Data, and IEC 61850
FE | | | | | | | | | PRP, CyberSentry Lvl 1, and two PMUs
FF | | | | | | | | | PRP, CyberSentry Lvl 1, IEC 61850, and two PMUs
G0 | | | | | | | | | IEEE 1588, PRP, and CyberSentry Lvl 1
G1 | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Ethernet Global Data
G3 | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and IEC 61850
G4 | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, Ethernet Global Data, and IEC 61850
GE | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and two PMUs
GF | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, and two PMUs
J0 | | | | | | | | | IEC 60870-5-103
J1 | | | | | | | | | IEC 60870-5-103 and EGD
J3 | | | | | | | | | IEC 60870-5-103 and IEC 61850
J4 | | | | | | | | | IEC 60870-5-103, EGD, and IEC 61850
JE | | | | | | | | | IEC 60870-5-103 and two PMUs
JF | | | | | | | | | IEC 60870-5-103, IEC 61850, and two PMUs
K0 | | | | | | | | | IEEE 1588, PRP, and IEC 60870-5-103
K1 | | | | | | | | | IEEE 1588, PRP, IEC 60870-5-103, and EGD
K3 | | | | | | | | | IEEE 1588, PRP, IEC 60870-5-103, and IEC 61850
K4 | | | | | | | | | IEEE 1588, PRP, IEC 60870-5-103, EGD, and IEC 61850
KE | | | | | | | | | IEEE 1588, PRP, IEC 60870-5-103, and two PMUs
KF | | | | | | | | | IEEE 1588, PRP, IEC 60870-5-103, IEC 61850, and two PMUs
L0 | | | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, and CyberSentry Lvl 1
L1 | | | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, CyberSentry Lvl 1, and EGD
L3 | | | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850
L4 | | | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, CyberSentry Lvl 1, EGD, and IEC 61850
LE | | | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, CyberSentry Lvl 1, and two PMUs
LF | | | | | | | | | IEC 60870-5-103, IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, and two PMUs
