6-6 C60 Breaker Protection System GE Multilin
6.2 STATUS 6 ACTUAL VALUES
6
For form-A contact outputs, the state of the voltage and current detectors is displayed as Off, VOff, IOff, On, IOn,
and VOn. For form-C contact outputs, the state is displayed as Off or On.
6.2.7 VIRTUAL OUTPUTS
PATH: ACTUAL VALUES  STATUS  VIRTUAL OUTPUTS
The present state of up to 96 virtual outputs is shown here. The first line of a message display indicates the ID of the virtual
output. For example, ‘Virt Op 1’ refers to the virtual output in terms of the default name-array index. The second line of the
display indicates the logic state of the virtual output, as calculated by the FlexLogic equation for that output.
6.2.8 AUTORECLOSE
PATH: ACTUAL VALUES  STATUS  AUTORECLOSE
The automatic reclosure shot count is shown here.
6.2.9 REMOTE DEVICES
a) STATUS
PATH: ACTUAL VALUES  STATUS  REMOTE DEVICES STATUS
The present state of the programmed remote devices is shown here. The ALL REMOTE DEVICES ONLINE message indicates
whether or not all programmed remote devices are online. If the corresponding state is "No", then at least one required
remote device is not online.
 VIRTUAL OUTPUTS

Virt Op 1
Off
Range: On, Off
MESSAGE
Virt Op 2
Off
Range: On, Off
↓
MESSAGE
Virt Op 96
Off
Range: On, Off
 AUTORECLOSE

AUTORECLOSE
SHOT COUNT: 0
Range: 0, 1, 2, 3, 4
 REMOTE DEVICES
 STATUS
All REMOTE DEVICES
ONLINE: No
Range: Yes, No
MESSAGE
REMOTE DEVICE 1
STATUS: Offline
Range: Online, Offline
MESSAGE
REMOTE DEVICE 2
STATUS: Offline
Range: Online, Offline
↓
MESSAGE
REMOTE DEVICE 16
STATUS: Offline
Range: Online, Offline
NOTE
