GE Multilin C60 Breaker Protection System 6-23
6 ACTUAL VALUES 6.3 METERING
6
6.3.8 PHASOR MEASUREMENT UNIT
PATH: ACTUAL VALUES  METERING  PHASOR MEASUREMENT UNIT  PMU 1(2)
The above actual values are displayed without the corresponding time stamp as they become available per the recording
rate setting. Also, the recording post-filtering setting is applied to these values.
6.3.9 PMU AGGREGATOR
PATH: ACTUAL VALUES  METERING  PHASOR MEASUREMENT UNIT  PMU AGGREGATOR 1(2)
 PMU 1

PMU 1 VA:
0.0000 kV, 0.00°
Range: Va or Vab per VT bank connection
MESSAGE
PMU 1 VB:
0.0000 kV, 0.00°
Range: Va or Vab per VT bank connection
MESSAGE
PMU 1 VC:
0.0000 kV, 0.00°
Range: Va or Vab per VT bank connection
MESSAGE
PMU 1 VX:
0.0000 kV, 0.00°
MESSAGE
PMU 1 V1:
0.0000 kV, 0.00°
MESSAGE
PMU 1 V2:
0.0000 kV, 0.00°
MESSAGE
PMU 1 V0:
0.0000 kV, 0.00°
Range: Substituted with zero if delta-connected VTs.
MESSAGE
PMU 1 IA:
0.0000 kA, 0.00°
MESSAGE
PMU 1 IB:
0.0000 kA, 0.00°
MESSAGE
PMU 1 IC:
0.0000 kA, 0.00°
MESSAGE
PMU 1 IG:
0.0000 kA, 0.00°
MESSAGE
PMU 1 I1:
0.0000 kA, 0.00°
MESSAGE
PMU 1 I2:
0.0000 kA, 0.00°
MESSAGE
PMU 1 I0:
0.0000 kA, 0.00°
MESSAGE
PMU 1 FREQUENCY:
0.0000 Hz
MESSAGE
PMU 1 df/dt:
0.0000 Hz/s
MESSAGE
PMU 1 CONFIG CHANGE
COUNTER: 0
Range: 0 to 65535
 PMU AGGREGATOR 1

PMU AGGREGATOR 1
PDU SIZE: 0
