GE Multilin C60 Breaker Protection System 6-17
6 ACTUAL VALUES 6.3 METERING
6
The metered phase current values are displayed in this menu. The "SRC 1" text will be replaced by whatever name was
programmed by the user for the associated source (see
SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).
c) GROUND CURRENT METERING
PATH: ACTUAL VALUES  METERING SOURCE SRC 1  GROUND CURRENT
The metered ground current values are displayed in this menu. The "SRC 1" text will be replaced by whatever name was
programmed by the user for the associated source (see
SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).
d) PHASE VOLTAGE METERING
PATH: ACTUAL VALUES  METERING SOURCE SRC 1 PHASE VOLTAGE
MESSAGE
SRC 1 ZERO SEQ I0:
0.000 A 0.0°
MESSAGE
SRC 1 POS SEQ I1:
0.000 A 0.0°
MESSAGE
SRC 1 NEG SEQ I2:
0.000 A 0.0°
GROUND CURRENT
SRC 1
SRC 1 RMS Ig:
0.000 A
MESSAGE
SRC 1 PHASOR Ig:
0.000 A 0.0°
MESSAGE
SRC 1 PHASOR Igd:
0.000 A 0.0°
PHASE VOLTAGE
SRC 1
SRC 1 RMS Vag:
0.00 V
MESSAGE
SRC 1 RMS Vbg:
0.00 V
MESSAGE
SRC 1 RMS Vcg:
0.00 V
MESSAGE
SRC 1 PHASOR Vag:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vbg:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vcg:
0.000 V 0.0°
MESSAGE
SRC 1 RMS Vab:
0.00 V
MESSAGE
SRC 1 RMS Vbc:
0.00 V
MESSAGE
SRC 1 RMS Vca:
0.00 V
MESSAGE
SRC 1 PHASOR Vab:
0.000 V 0.0°
MESSAGE
SRC 1 PHASOR Vbc:
0.000 V 0.0°
