B-26 C60 Breaker Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
3808 Field Unit 1 Serial Number 1 to1 --- 1 F205 "000000000000"
380E Field Unit 1 Port 1 to 4 --- 1 F001 1
380F ...Repeated for Field Unit 2
381E ...Repeated for Filed Unit 3
382D ...Repeated for Filed Unit 4
383C ...Repeated for Filed Unit 5
384B ...Repeated for Filed Unit 6
385A ...Repeated for Filed Unit 7
3869 ...Repeated for Filed Unit 8
Field Unit Process Card Ports (Read/Write Setting)
3878 Field Unit 1 Process Card Port 0 to 7 --- 1 F244 6 (H1a)
3879 Field Unit 2 Process Card Port 0 to 7 --- 1 F244 4 (H2a)
387A Field Unit3 Process Card Port 0 to 7 --- 1 F244 2 (H3a)
387B Field Unit 4 Process Card Port 0 to 7 --- 1 F244 0 (H4a)
387C Field Unit 5 Process Card Port 0 to 7 --- 1 F244 7 (H1b)
387D Field Unit 6 Process Card Port 0 to 7 --- 1 F244 5 (H2b)
387E Field Unit 7 Process Card Port 0 to 7 --- 1 F244 3 (H3b)
387F Field Unit 8 Process Card Port 0 to 7 --- 1 F244 1 (H4b)
Field Unit CT VT Settings (Read/Write Setting) (6 modules)
3890 Remote Phase CT x Origin 1 0 to 16 --- 1 F247 0 (None)
3891 Remote Phase CT x Origin 2 0 to 16 --- 1 F247 0 (None)
3892 Remote Ground CT x Origin 1 0 to 16 --- 1 F248 0 (None)
3893 Remote Ground CT x Origin 2 0 to 16 --- 1 F248 0 (None)
3894 AC Bank Redundancy Type 0 to 2 --- 1 F261 1 (Dependability
Biased)
3895 Remote Phase CT 1 Primary 1 to 65000 --- 1 F001 1
3896 Remote Phase CT 1 Secondary 0 to 1 --- 1 F123 0 (1 A)
3897 Remote Ground CT 1 Primary 1 to 65000 --- 1 F001 1
3898 Remote Ground CT 1 Secondary 0 to 1 --- 1 F123 0 (1 A)
3899 Remote Phase VT 1 Connection 0 to 1 --- 1 F100 0 (Wye)
389A Remote Phase VT 1 Secondary 25 to 240 --- 0.1 F001 664
389B Remote Phase VT 1 Ratio 1 to 24000 --- 1 F060 1
389D Remote Auxiliary VT 1 Connection 0 to 6 --- 1 F166 1 (Vag)
389E Remote Auxiliary VT 1 Secondary 25 to 240 --- 0.1 F001 664
389F Remote Auxiliary VT 1 Ratio 1 to 24000 --- 1 F060 1
38A1 ...Repeated for Field Unit 2
38B2 ...Repeated for Field Unit 3
38C3 ...Repeated for Field Unit 4
38D4 ...Repeated for Field Unit 5
38E5 ...Repeated for Field Unit 6
Field Unit Contact Inputs (Read/Write Setting) (40 modules)
3900 Field Contact Input 1 ID --- --- --- F205 "FCI 1"
3906 Field Contact Input 1 Origin 0 to 8 --- 1 F256 0 (None)
3907 Field Contact Input 1 Input 1 to 18 --- 1 F001 1
3908 Field Contact Input 1 Failsafe Value 0 to 1 --- 1 F108 0 (Off)
3909 Field Contact Input 1 Debounce Time 0 to 16 ms 0.5 F001 20
390A Field Contact Input 1 Events 0 to 1 --- 1 F102 1 (Enabled)
390B ...Repeated for Field Contact Input 2
3916 ...Repeated for Field Contact Input 3
3921 ...Repeated for Field Contact Input 4
392C ...Repeated for Field Contact Input 5
3937 ...Repeated for Field Contact Input 6
3942 ...Repeated for Field Contact Input 7
394D ...Repeated for Field Contact Input 8
Table B–10: MODBUS MEMORY MAP (Sheet 18 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
