B-38 C60 Breaker Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
5818 ...Repeated for FlexLogic Timer 4
5820 ...Repeated for FlexLogic Timer 5
5828 ...Repeated for FlexLogic Timer 6
5830 ...Repeated for FlexLogic Timer 7
5838 ...Repeated for FlexLogic Timer 8
5840 ...Repeated for FlexLogic Timer 9
5848 ...Repeated for FlexLogic Timer 10
5850 ...Repeated for FlexLogic Timer 11
5858 ...Repeated for FlexLogic Timer 12
5860 ...Repeated for FlexLogic Timer 13
5868 ...Repeated for FlexLogic Timer 14
5870 ...Repeated for FlexLogic Timer 15
5878 ...Repeated for FlexLogic Timer 16
5880 ...Repeated for FlexLogic Timer 17
5888 ...Repeated for FlexLogic Timer 18
5890 ...Repeated for FlexLogic Timer 19
5898 ...Repeated for FlexLogic Timer 20
58A0 ...Repeated for FlexLogic Timer 21
58A8 ...Repeated for FlexLogic Timer 22
58B0 ...Repeated for FlexLogic Timer 23
58B8 ...Repeated for FlexLogic Timer 24
58C0 ...Repeated for FlexLogic Timer 25
58C8 ...Repeated for FlexLogic Timer 26
58D0 ...Repeated for FlexLogic Timer 27
58D8 ...Repeated for FlexLogic Timer 28
58E0 ...Repeated for FlexLogic Timer 29
58E8 ...Repeated for FlexLogic Timer 30
58F0 ...Repeated for FlexLogic Timer 31
58F8 ...Repeated for FlexLogic Timer 32
Phase Time Overcurrent (Read/Write Grouped Setting) (6 modules)
5900 Phase Time Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5901 Phase Time Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
5902 Phase Time Overcurrent 1 Input 0 to 1 --- 1 F122 0 (Phasor)
5903 Phase Time Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
5904 Phase Time Overcurrent 1 Curve 0 to 16 --- 1 F103 0 (IEEE Mod Inv)
5905 Phase Time Overcurrent 1 Multiplier 0 to 600 --- 0.01 F001 100
5906 Phase Time Overcurrent 1 Reset 0 to 1 --- 1 F104 0 (Instantaneous)
5907 Phase Time Overcurrent 1 Voltage Restraint 0 to 1 --- 1 F102 0 (Disabled)
5908 Phase TOC 1 Block For Each Phase (3 items) 0 to 4294967295 --- 1 F300 0
590F Phase Time Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
5910 Phase Time Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
5911 Reserved (3 items) 0 to 1 --- 1 F001 0
5914 ...Repeated for Phase Time Overcurrent 2
5928 ...Repeated for Phase Time Overcurrent 3
593C ...Repeated for Phase Time Overcurrent 4
5950 ...Repeated for Phase Time Overcurrent 5
5964 ...Repeated for Phase Time Overcurrent 6
Phase Instantaneous Overcurrent (Read/Write Grouped Setting) (8 modules)
5A00 Phase Instantaneous Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5A01 Phase Instantaneous Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
5A02 Phase Instantaneous Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
5A03 Phase Instantaneous Overcurrent 1 Delay 0 to 600 s 0.01 F001 0
5A04 Phase Instantaneous Overcurrent 1 Reset Delay 0 to 600 s 0.01 F001 0
5A05 Phase IOC1 Block For Each Phase (3 items) 0 to 4294967295 --- 1 F300 0
Table B–10: MODBUS MEMORY MAP (Sheet 30 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
