GE Multilin C60 Breaker Protection System B-63
APPENDIX B B.4 MEMORY MAPPING
B
C432 Test Mode Initiate 0 to 4294967295 --- 1 F300 1
Clear Commands (Read/Write)
C434 Clear All Relay Records Command 0 to 1 --- 1 F126 0 (No)
Mandatory (Read Only)
C435 DSP Advanced Diagnostics Active 0 to 1 -- 1 F126 0 (No)
C436 Synchrophasor Feature Active 0 to 1 -- 1 F126 0 (No)
Mandatory (Read/Write Command)
C437 Relay Reboot Command 0 to 1 --- 1 F126 0 (No)
C438 Save Volatile Data 0 to 1 --- 1 F126 0 (No)
Clear Records (Read/Write Setting)
C446 Clear Demand Operand 0 to 4294967295 --- 1 F300 0
C450 Clear Fault Reports Operand 0 to 4294967295 --- 1 F300 0
C454 Clear Event Records Operand 0 to 4294967295 --- 1 F300 0
C456 Clear Oscillography Operand 0 to 4294967295 --- 1 F300 0
C458 Clear Data Logger Operand 0 to 4294967295 --- 1 F300 0
C45A Clear Breaker 1 Arcing Current Operand 0 to 4294967295 --- 1 F300 0
C45C Clear Breaker 2 Arcing Current Operand 0 to 4294967295 --- 1 F300 0
C45E Clear Breaker 3 Arcing Current Operand 0 to 4294967295 --- 1 F300 0
C460 Clear Breaker 4 Arcing Current Operand 0 to 4294967295 --- 1 F300 0
C468 Clear Energy Operand 0 to 4294967295 --- 1 F300 0
C46C Clear Unauthorized Access Operand 0 to 4294967295 --- 1 F300 0
C470 Clear Platform Direct Input/Output Statistics Operand 0 to 4294967295 --- 1 F300 0
C472 Reserved (13 items) --- --- --- F001 0
Platform Direct Outputs (Read/Write Setting) (32 modules)
C600 Direct Output 1 Operand 0 to 4294967295 --- 1 F300 0
C602 Direct Output 1 Events 0 to 1 --- 1 F102 0 (Disabled)
C603 ...Repeated for Direct Output 2
C606 ...Repeated for Direct Output 3
C609 ...Repeated for Direct Output 4
C60C ...Repeated for Direct Output 5
C60F ...Repeated for Direct Output 6
C612 ...Repeated for Direct Output 7
C615 ...Repeated for Direct Output 8
C618 ...Repeated for Direct Output 9
C61B ...Repeated for Direct Output 10
C61E ...Repeated for Direct Output 11
C621 ...Repeated for Direct Output 12
C624 ...Repeated for Direct Output 13
C627 ...Repeated for Direct Output 14
C62A ...Repeated for Direct Output 15
C62D ...Repeated for Direct Output 16
C630 ...Repeated for Direct Output 17
C633 ...Repeated for Direct Output 18
C636 ...Repeated for Direct Output 19
C639 ...Repeated for Direct Output 20
C63C ...Repeated for Direct Output 21
C63F ...Repeated for Direct Output 22
C642 ...Repeated for Direct Output 23
C645 ...Repeated for Direct Output 24
C648 ...Repeated for Direct Output 25
C64B ...Repeated for Direct Output 26
C64E ...Repeated for Direct Output 27
C651 ...Repeated for Direct Output 28
C654 ...Repeated for Direct Output 29
Table B–10: MODBUS MEMORY MAP (Sheet 55 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
