B-66 C60 Breaker Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
CD2B ...Repeated for Device 16
Remote Inputs (Read/Write Setting) (32 modules)
CFA0 Remote Input 1 Device 1 to 32 --- 1 F001 1
CFA1 Remote Input 1 Bit Pair 0 to 96 --- 1 F156 0 (None)
CFA2 Remote Input 1 Default State 0 to 3 --- 1 F086 0 (Off)
CFA3 Remote Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
CFA4 Remote Input 1 Name 1 to 64 --- 1 F205 “Rem Ip 1”
CFAA ...Repeated for Remote Input 2
CFB4 ...Repeated for Remote Input 3
CFBE ...Repeated for Remote Input 4
CFC8 ...Repeated for Remote Input 5
CFD2 ...Repeated for Remote Input 6
CFDC ...Repeated for Remote Input 7
CFE6 ...Repeated for Remote Input 8
CFF0 ...Repeated for Remote Input 9
CFFA ...Repeated for Remote Input 10
D004 ...Repeated for Remote Input 11
D00E ...Repeated for Remote Input 12
D018 ...Repeated for Remote Input 13
D022 ...Repeated for Remote Input 14
D02C ...Repeated for Remote Input 15
D036 ...Repeated for Remote Input 16
D040 ...Repeated for Remote Input 17
D04A ...Repeated for Remote Input 18
D054 ...Repeated for Remote Input 19
D05E ...Repeated for Remote Input 20
D068 ...Repeated for Remote Input 21
D072 ...Repeated for Remote Input 22
D07C ...Repeated for Remote Input 23
D086 ...Repeated for Remote Input 24
D090 ...Repeated for Remote Input 25
D09A ...Repeated for Remote Input 26
D0A4 ...Repeated for Remote Input 27
D0AE ...Repeated for Remote Input 28
D0B8 ...Repeated for Remote Input 29
D0C2 ...Repeated for Remote Input 30
D0CC ...Repeated for Remote Input 31
D0D6 ...Repeated for Remote Input 32
Remote Output DNA Pairs (Read/Write Setting) (32 modules)
D220 Remote Output DNA 1 Operand 0 to 4294967295 --- 1 F300 0
D222 Remote Output DNA 1 Events 0 to 1 --- 1 F102 0 (Disabled)
D223 Reserved 0 to 1 --- 1 F001 0
D224 ...Repeated for Remote Output 2
D228 ...Repeated for Remote Output 3
D22C ...Repeated for Remote Output 4
D230 ...Repeated for Remote Output 5
D234 ...Repeated for Remote Output 6
D238 ...Repeated for Remote Output 7
D23C ...Repeated for Remote Output 8
D240 ...Repeated for Remote Output 9
D244 ...Repeated for Remote Output 10
D248 ...Repeated for Remote Output 11
D24C ...Repeated for Remote Output 12
D250 ...Repeated for Remote Output 13
Table B–10: MODBUS MEMORY MAP (Sheet 58 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
