B-74 C60 Breaker Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
Phasor Measurement Unit Calibration (Read/Write Setting) (2 modules)
EBDC PMU 1 Va Calibration Angle -5 to 5 ° 0.05 F002 0
EBDD PMU 1 Va Calibration Magnitude 95 to 105 % 0.1 F002 1000
EBDE PMU 1 Vb Calibration Angle -5 to 5 ° 0.05 F002 0
EBDF PMU 1 Vb Calibration Magnitude 95 to 105 % 0.1 F002 1000
EBE0 PMU 1 Vc Calibration Angle -5 to 5 ° 0.05 F002 0
EBE1 PMU 1 Vc Calibration Magnitude 95 to 105 % 0.1 F002 1000
EBE2 PMU 1 Vx Calibration Angle -5 to 5 ° 0.05 F002 0
EBE3 PMU 1 Vx Calibration Magnitude 95 to 105 % 0.1 F002 1000
EBE4 PMU 1 Ia Calibration Angle -5 to 5 ° 0.05 F002 0
EBE5 PMU 1 Ia Calibration Magnitude 95 to 105 % 0.1 F002 1000
EBE6 PMU 1 Ib Calibration Angle -5 to 5 ° 0.05 F002 0
EBE7 PMU 1 Ib Calibration Magnitude 95 to 105 % 0.1 F002 1000
EBE8 PMU 1 Ic Calibration Angle -5 to 5 ° 0.05 F002 0
EBE9 PMU 1 Ic Calibration Magnitude 95 to 105 % 0.1 F002 1000
EBEA PMU 1 Ig Calibration Angle -5 to 5 ° 0.05 F002 0
EBEB PMU 1 Ig Calibration Magnitude 95 to 105 % 0.1 F002 1000
EBEC PMU 1 Sequence Voltage Shift Angle -180 to 180 ° 30 F002 0
EBED PMU 1 Sequence Current Shift Angle -180 to 180 ° 30 F002 0
EBEE ...Repeated for PMU 2
Phasor Measurement Unit Network Reporting Configuration (Read/Write Setting)
EC48 PMU Network Reporting Function 0 to 1 --- 1 F102 0 (Disabled)
EC49 PMU Network Reporting ID Code 1 to 65534 --- 1 F001 1
EC4A PMU TCP Port Number 1 to 65535 --- 1 F001 4712
EC4B PMU UDP Port Number 1 1 to 65535 --- 1 F001 4713
EC4C PMU UDP Port Number 2 1 to 65535 --- 1 F001 4714
Settings File Template (Read/Write Setting)
ED00 FlexLogic Displays Active 0 to 1 --- 1 F102 1 (Enabled)
ED01 Template Access --- --- --- F205 (none)
Setting File Template (Read Only Non-Volatile)
ED07 Last Settings Change Date 0 to 4294967295 --- 1 F050 0
Settings File Template (Read/Write Setting)
ED09 Template Bitmask (750 items) 0 to 65535 --- 1 F001 0
Phasor Measurement Unit Records (Read Only)
EFFF PMU Recording Number of Triggers 0 to 65535 --- 1 F001 0
Table B–10: MODBUS MEMORY MAP (Sheet 66 of 66)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
