GE Multilin C60 Breaker Protection System B-77
APPENDIX B B.4 MEMORY MAPPING
B
20 Phase Time Overcurrent 5
21 Phase Time Overcurrent 6
32 Neutral Instantaneous Overcurrent 1
33 Neutral Instantaneous Overcurrent 2
34 Neutral Instantaneous Overcurrent 3
35 Neutral Instantaneous Overcurrent 4
36 Neutral Instantaneous Overcurrent 5
37 Neutral Instantaneous Overcurrent 6
38 Neutral Instantaneous Overcurrent 7
39 Neutral Instantaneous Overcurrent 8
48 Neutral Time Overcurrent 1
49 Neutral Time Overcurrent 2
50 Neutral Time Overcurrent 3
51 Neutral Time Overcurrent 4
52 Neutral Time Overcurrent 5
53 Neutral Time Overcurrent 6
140 Auxiliary Undervoltage 1
141 Auxiliary Undervoltage 2
144 Phase Undervoltage 1
145 Phase Undervoltage 2
146 Phase Undervoltage 3
148 Auxiliary Overvoltage 1
149 Auxiliary Overvoltage 2
151 Phase Overvoltage 1
152 Phase Overvoltage 2
153 Phase Overvoltage 3
156 Neutral Overvoltage 1
157 Neutral Overvoltage 2
158 Neutral Overvoltage 3
214 Sensitive Directional Power 1
215 Sensitive Directional Power 2
224 SRC1 VT Fuse Failure
225 SRC2 VT Fuse Failure
226 SRC3 VT Fuse Failure
227 SRC4 VT Fuse Failure
232 SRC1 50DD (Disturbance Detection)
233 SRC2 50DD (Disturbance Detection)
234 SRC3 50DD (Disturbance Detection)
235 SRC4 50DD (Disturbance Detection)
242 Open Pole Detector
280 Breaker Failure 1
281 Breaker Failure 2
288 Breaker Arcing Current 1
289 Breaker Arcing Current 2
290 Breaker Arcing Current 3
291 Breaker Arcing Current 4
294 Breaker 1 Flashover
295 Breaker 2 Flashover
311 Phasor measurement unit one-shot
312 Synchrocheck 1
313 Synchrocheck 2
314 Synchrocheck 3
315 Synchrocheck 4
Bitmask Element
336 Setting Group
337 Reset
363 Open Pole Detector
375 Autoreclose (single-pole / three-pole)
388 Selector switch 1
389 Selector switch 2
390 Control pushbutton 1
391 Control pushbutton 2
392 Control pushbutton 3
393 Control pushbutton 4
394 Control pushbutton 5
395 Control pushbutton 6
396 Control pushbutton 7
400 FlexElement 1
401 FlexElement 2
402 FlexElement 3
403 FlexElement 4
404 FlexElement 5
405 FlexElement 6
406 FlexElement 7
407 FlexElement 8
420 Non-volatile Latch 1
421 Non-volatile Latch 2
422 Non-volatile Latch 3
423 Non-volatile Latch 4
424 Non-volatile Latch 5
425 Non-volatile Latch 6
426 Non-volatile Latch 7
427 Non-volatile Latch 8
428 Non-volatile Latch 9
429 Non-volatile Latch 10
430 Non-volatile Latch 11
431 Non-volatile Latch 12
432 Non-volatile Latch 13
433 Non-volatile Latch 14
434 Non-volatile Latch 15
435 Non-volatile Latch 16
544 Digital Counter 1
545 Digital Counter 2
546 Digital Counter 3
547 Digital Counter 4
548 Digital Counter 5
549 Digital Counter 6
550 Digital Counter 7
551 Digital Counter 8
692 Digital Element 1
693 Digital Element 2
694 Digital Element 3
695 Digital Element 4
696 Digital Element 5
697 Digital Element 6
698 Digital Element 7
699 Digital Element 8
Bitmask Element
