Connect the wires
S
TEP 1
Connect the neutral (white) wire on the switch to the neutral (white
label) wire from the wall.
STEP 2
The line and load wires are interchangeable. Connect either black wire
on the switch to the line (black label) wire from the wall.
STEP 3
Connect the other black wire on the switch to the load (black label)
wire on the wall.
STEP 4
Connect the ground (green) wire on the switch with the ground
(green label) wire from the wall.
Attention: Incorrectly connecting the Neutral or Ground wire from the
wall to the Line or Load wire on the switch will damage the product.
