GE G60

GE Multilin G60 Generator Protection System B-11
APPENDIX B B.4 MEMORY MAPPING
B
Digital Counter States Actual Values (Read Only Non-Volatile) (8 modules)
0800 Digital Counter 1 Value -2147483647 to
2147483647
--- 1 F004 0
0802 Digital Counter 1 Frozen -2147483647 to
2147483647
--- 1 F004 0
0804 Digital Counter 1 Frozen Time Stamp 0 to 4294967295 --- 1 F050 0
0806 Digital Counter 1 Frozen Time Stamp us (microsecond part
of time stamp)
0 to 4294967295 --- 1 F003 0
0808 ...Repeated for Digital Counter 2
0810 ...Repeated for Digital Counter 3
0818 ...Repeated for Digital Counter 4
0820 ...Repeated for Digital Counter 5
0828 ...Repeated for Digital Counter 6
0830 ...Repeated for Digital Counter 7
0838 ...Repeated for Digital Counter 8
FlexStates (Read Only)
0900 FlexState Bits (16 items) 0 to 65535 --- 1 F001 0
Element States (Read Only)
1000 Element Operate States (64 items) 0 to 65535 --- 1 F502 0
User Displays Actuals (Read Only)
1080 Formatted user-definable displays (16 items) --- --- --- F200 (none)
Modbus User Map Actuals (Read Only)
1200 User Map Values (256 items) 0 to 65535 --- 1 F001 0
Element Targets (Read Only)
14E0 Target Sequence 0 to 65535 --- 1 F001 0
14E1 Number of Targets 0 to 65535 --- 1 F001 0
Element Targets (Read/Write)
14E2 Target to Read 0 to 65535 --- 1 F001 0
Element Targets (Read Only)
14E3 Target Message --- --- --- F200 “.”
Contact Input/Output States (Read Only)
1500 Contact Input States (6 items) 0 to 65535 --- 1 F500 0
1508 Virtual Input States (8 items) 0 to 65535 --- 1 F500 0
1510 Contact Output States (4 items) 0 to 65535 --- 1 F500 0
1518 Contact Output Current States (4 items) 0 to 65535 --- 1 F500 0
1520 Contact Output Voltage States (4 items) 0 to 65535 --- 1 F500 0
1528 Virtual Output States (6 items) 0 to 65535 --- 1 F500 0
1530 Contact Output Detectors (4 items) 0 to 65535 --- 1 F500 0
Remote Input/Output States (Read Only)
1540 Remote Device States (2 items) 0 to 65535 --- 1 F500 0
1542 Remote Input States (4 items) 0 to 65535 --- 1 F500 0
1550 Remote Devices Online 0 to 1 --- 1 F126 0 (No)
1551 Remote Double-Point Status Input 1 State 0 to 3 --- 1 F605 3 (Bad)
1552 Remote Double-Point Status Input 2 State 0 to 3 --- 1 F605 3 (Bad)
1553 Remote Double-Point Status Input 3 State 0 to 3 --- 1 F605 3 (Bad)
1554 Remote Double-Point Status Input 4 State 0 to 3 --- 1 F605 3 (Bad)
1555 Remote Double-Point Status Input 5 State 0 to 3 --- 1 F605 3 (Bad)
Platform Direct Input/Output States (Read Only)
15C0 Direct Input States (6 items) 0 to 65535 --- 1 F500 0
15C8 Direct Outputs Average Message Return Time 1 0 to 65535 ms 1 F001 0
15C9 Direct Outputs Average Message Return Time 2 0 to 65535 ms 1 F001 0
15CA Direct Inputs/Outputs Unreturned Message Count - Ch. 1 0 to 65535 --- 1 F001 0
15CB Direct Inputs/Outputs Unreturned Message Count - Ch. 2 0 to 65535 --- 1 F001 0
15D0 Direct Device States 0 to 65535 --- 1 F500 0
15D1 Reserved 0 to 65535 --- 1 F001 0
Table B–10: MODBUS MEMORY MAP (Sheet 3 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
