GE G60

B-12 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
15D2 Direct Inputs/Outputs CRC Fail Count 1 0 to 65535 --- 1 F001 0
15D3 Direct Inputs/Outputs CRC Fail Count 2 0 to 65535 --- 1 F001 0
Field Unit Input/Output States (Read Only)
15E0 Field Unit Contact Input States (3 items) 0 to 65535 --- 1 F500 0
15E3 Field Unit Contact Input Output Operand States (8 items) 0 to 65535 --- 1 F500 0
15EB Field Contact Output Physical States (8 items) 0 to 65535 --- 1 F500 0
15F3 Field Contact Output Current States (8 items) 0 to 65535 --- 1 F500 0
15FB Field Contact Output Physical States (8 items) 0 to 65535 --- 1 F500 0
1603 Field Shared Input States 0 to 65535 --- 1 F500 0
1604 Field Shared Input Channel States 0 to 65535 --- 1 F500 0
1605 Field Shared Input Test States 0 to 65535 --- 1 F500 0
1606 Field Shared Output Operand States 0 to 65535 --- 1 F500 0
1607 Field Latching Output Open Operand States 0 to 65535 --- 1 F500 0
1608 Field Latching Output Close Operand States 0 to 65535 --- 1 F500 0
1609 Field Latching Output Open Driver States 0 to 65535 --- 1 F500 0
160A Field Latching Output Close Driver States 0 to 65535 --- 1 F500 0
160B Field Latching Output Physical States 0 to 65535 --- 1 F500 0
160C Field Unit Online/Offline States 0 to 65535 --- 1 F500 0
160D Field RTD Input Trouble States 0 to 65535 --- 1 F500 0
160E Field Transducer Input Trouble States 0 to 65535 --- 1 F500 0
Ethernet Fibre Channel Status (Read Only)
1610 Ethernet Primary Fibre Channel Status 0 to 2 --- 1 F134 0 (Fail)
1611 Ethernet Secondary Fibre Channel Status 0 to 2 --- 1 F134 0 (Fail)
1612 Ethernet Tertiary Fibre Channel Status 0 to 2 --- 1 F134 0 (Fail)
Data Logger Actual Values (Read Only)
1618 Data Logger Channel Count 0 to 16 channel 1 F001 0
1619 Time of Oldest Available Samples 0 to 4294967295 seconds 1 F050 0
161B Time of Newest Available Samples 0 to 4294967295 seconds 1 F050 0
161D Data Logger Duration 0 to 999.9 days 0.1 F001 0
Stator Differential Actual Values (Read Only)
1660 Generator Differential Iad 0 to 999999.999 A 0.001 F060 0
1662 Generator Restraint Iar 0 to 999999.999 A 0.001 F060 0
1664 Generator Differential Ibd 0 to 999999.999 A 0.001 F060 0
1666 Generator Restraint Ibr 0 to 999999.999 A 0.001 F060 0
1668 Generator Differential Icd 0 to 999999.999 A 0.001 F060 0
166A Generator Restraint Icr 0 to 999999.999 A 0.001 F060 0
166C Stator Differential CT Primary 0 to 50000 --- 1 F060 1
Stator Ground Actual Values (Read Only)
1670 Stator Ground Vn 3rd 0 to 999999.999 V 0.001 F060 0
1672 Stator Ground Vn V0 3rd 0 to 999999.999 V 0.001 F060 0
1674 Stator Ground V0 3rd 0 to 999999.999 V 0.001 F060 0
Subharmonic Stator Ground Actual Values (Read Only)
1678 Subharmonic Injection Voltage 0 to 999999.999 V 0.001 F060 0
167A Subharmonic Injection Current 0 to 999999.999 A 0.001 F060 0
167C Stator Ground Resistance 0 to 500 kOhm 0.001 F003 500000
167E Reserved 0 to 0.1 --- 0.1 F208 (none)
167F Subharmonic Injection Current Angle -360 to 360 --- 0.1 F002 0
Sensitive Directional Power Actual Values (Read Only) (2 modules)
1680 Sensitive Directional Power 1 Power
-2147483647 to 2147483647
W1F060 0
1682 Sensitive Directional Power 2 Power
-2147483647 to 2147483647
W1F060 0
Restricted Ground Fault Currents (Read Only) (6 modules)
16A0 Differential Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
16A2 Restricted Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
16A4 ...Repeated for Restricted Ground Fault 2
Table B–10: MODBUS MEMORY MAP (Sheet 4 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
