GE Multilin G60 Generator Protection System B-17
APPENDIX B B.4 MEMORY MAPPING
B
2622 Remote Double-Point Status Input 1 Name 1 to 64 --- 1 F205 "RemDPS Ip 1"
2628 Remote Double-Point Status Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
2629 ... Repeated for Double-Point Status Input 2
2632 ... Repeated for Double-Point Status Input 3
263B ... Repeated for Double-Point Status Input 4
2644 ... Repeated for Double-Point Status Input 5
Phasor Measurement Unit Aggregator Actual Values (Read Only)
2650 PMU 1 Aggregator PDU Size --- --- --- F001 0
IEC 61850 GGIO5 Configuration (Read/Write Setting Registers) (16 modules)
26B0 IEC 61850 GGIO5 uinteger Input 1 Operand --- --- --- F612 0
26B1 IEC 61850 GGIO5 uinteger Input 2 Operand --- --- --- F612 0
26B2 IEC 61850 GGIO5 uinteger Input 3 Operand --- --- --- F612 0
26B3 IEC 61850 GGIO5 uinteger Input 4 Operand --- --- --- F612 0
26B4 IEC 61850 GGIO5 uinteger Input 5 Operand --- --- --- F612 0
26B5 IEC 61850 GGIO5 uinteger Input 6 Operand --- --- --- F612 0
26B6 IEC 61850 GGIO5 uinteger Input 7 Operand --- --- --- F612 0
26B7 IEC 61850 GGIO5 uinteger Input 8 Operand --- --- --- F612 0
26B8 IEC 61850 GGIO5 uinteger Input 9 Operand --- --- --- F612 0
26B9 IEC 61850 GGIO5 uinteger Input 10 Operand --- --- --- F612 0
26BA IEC 61850 GGIO5 uinteger Input 11 Operand --- --- --- F612 0
26BB IEC 61850 GGIO5 uinteger Input 12 Operand --- --- --- F612 0
26BC IEC 61850 GGIO5 uinteger Input 13 Operand --- --- --- F612 0
26BD IEC 61850 GGIO5 uinteger Input 14 Operand --- --- --- F612 0
26BE IEC 61850 GGIO5 uinteger Input 15 Operand --- --- --- F612 0
26BF IEC 61850 GGIO5 uinteger Input 16 Operand --- --- --- F612 0
IEC 61850 Received Integers (Read Only Actual Values) (16 modules)
26F0 IEC 61850 Received uinteger 1 0 to 4294967295 --- 1 F003 0
26F2 IEC 61850 Received uinteger 2 0 to 4294967295 --- 1 F003 0
26F4 IEC 61850 Received uinteger 3 0 to 4294967295 --- 1 F003 0
26F6 IEC 61850 Received uinteger 4 0 to 4294967295 --- 1 F003 0
26F8 IEC 61850 Received uinteger 5 0 to 4294967295 --- 1 F003 0
26FA IEC 61850 Received uinteger 6 0 to 4294967295 --- 1 F003 0
26FC IEC 61850 Received uinteger 7 0 to 4294967295 --- 1 F003 0
26FE IEC 61850 Received uinteger 8 0 to 4294967295 --- 1 F003 0
2700 IEC 61850 Received uinteger 9 0 to 4294967295 --- 1 F003 0
2702 IEC 61850 Received uinteger 10 0 to 4294967295 --- 1 F003 0
2704 IEC 61850 Received uinteger 11 0 to 4294967295 --- 1 F003 0
2706 IEC 61850 Received uinteger 12 0 to 4294967295 --- 1 F003 0
2708 IEC 61850 Received uinteger 13 0 to 4294967295 --- 1 F003 0
270A IEC 61850 Received uinteger 14 0 to 4294967295 --- 1 F003 0
270C IEC 61850 Received uinteger 15 0 to 4294967295 --- 1 F003 0
270E IEC 61850 Received uinteger 16 0 to 4294967295 --- 1 F003 0
Source Current THD and Harmonics (Read Only) (4 modules)
2800 Ia THD for Source 1 0 to 99.9 --- 0.1 F001 0
2801 Ia Harmonics for Source 1 - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
2821 Ib THD for Source 1 0 to 99.9 --- 0.1 F001 0
2822 Ib Harmonics for Source 1 - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
283A Reserved (8 items) 0 to 0.1 --- 0.1 F001 0
2842 Ic THD for Source 1 0 to 99.9 --- 0.1 F001 0
2843 Ic Harmonics for Source 1 - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
285B Reserved (8 items) 0 to 0.1 --- 0.1 F001 0
2863 ...Repeated for Source 2
28C6 ...Repeated for Source 3
2929 ...Repeated for Source 4
Table B–10: MODBUS MEMORY MAP (Sheet 9 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
