B-20 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
34C6 DCMA Inputs 4 Value -9999.999 to 9999.999 --- 0.001 F004 0
34C8 DCMA Inputs 5 Value -9999.999 to 9999.999 --- 0.001 F004 0
34CA DCMA Inputs 6 Value -9999.999 to 9999.999 --- 0.001 F004 0
34CC DCMA Inputs 7 Value -9999.999 to 9999.999 --- 0.001 F004 0
34CE DCMA Inputs 8 Value -9999.999 to 9999.999 --- 0.001 F004 0
34D0 DCMA Inputs 9 Value -9999.999 to 9999.999 --- 0.001 F004 0
34D2 DCMA Inputs 10 Value -9999.999 to 9999.999 --- 0.001 F004 0
34D4 DCMA Inputs 11 Value -9999.999 to 9999.999 --- 0.001 F004 0
34D6 DCMA Inputs 12 Value -9999.999 to 9999.999 --- 0.001 F004 0
34D8 DCMA Inputs 13 Value -9999.999 to 9999.999 --- 0.001 F004 0
34DA DCMA Inputs 14 Value -9999.999 to 9999.999 --- 0.001 F004 0
34DC DCMA Inputs 15 Value -9999.999 to 9999.999 --- 0.001 F004 0
34DE DCMA Inputs 16 Value -9999.999 to 9999.999 --- 0.001 F004 0
34E0 DCMA Inputs 17 Value -9999.999 to 9999.999 --- 0.001 F004 0
34E2 DCMA Inputs 18 Value -9999.999 to 9999.999 --- 0.001 F004 0
34E4 DCMA Inputs 19 Value -9999.999 to 9999.999 --- 0.001 F004 0
34E6 DCMA Inputs 20 Value -9999.999 to 9999.999 --- 0.001 F004 0
34E8 DCMA Inputs 21 Value -9999.999 to 9999.999 --- 0.001 F004 0
34EA DCMA Inputs 22 Value -9999.999 to 9999.999 --- 0.001 F004 0
34EC DCMA Inputs 23 Value -9999.999 to 9999.999 --- 0.001 F004 0
34EE DCMA Inputs 24 Value -9999.999 to 9999.999 --- 0.001 F004 0
RTD Input Values (Read Only) (48 modules)
34F0 RTD Input 1 Value -32768 to 32767 °C 1 F002 0
34F1 RTD Input 2 Value -32768 to 32767 °C 1 F002 0
34F2 RTD Input 3 Value -32768 to 32767 °C 1 F002 0
34F3 RTD Input 4 Value -32768 to 32767 °C 1 F002 0
34F4 RTD Input 5 Value -32768 to 32767 °C 1 F002 0
34F5 RTD Input 6 Value -32768 to 32767 °C 1 F002 0
34F6 RTD Input 7 Value -32768 to 32767 °C 1 F002 0
34F7 RTD Input 8 Value -32768 to 32767 °C 1 F002 0
34F8 RTD Input 9 Value -32768 to 32767 °C 1 F002 0
34F9 RTD Input 10 Value -32768 to 32767 °C 1 F002 0
34FA RTD Input 11 Value -32768 to 32767 °C 1 F002 0
34FB RTD Input 12 Value -32768 to 32767 °C 1 F002 0
34FC RTD Input 13 Value -32768 to 32767 °C 1 F002 0
34FD RTD Input 14 Value -32768 to 32767 °C 1 F002 0
34FE RTD Input 15 Value -32768 to 32767 °C 1 F002 0
34FF RTD Input 16 Value -32768 to 32767 °C 1 F002 0
3500 RTD Input 17 Value -32768 to 32767 °C 1 F002 0
3501 RTD Input 18 Value -32768 to 32767 °C 1 F002 0
3502 RTD Input 19 Value -32768 to 32767 °C 1 F002 0
3503 RTD Input 20 Value -32768 to 32767 °C 1 F002 0
3504 RTD Input 21 Value -32768 to 32767 °C 1 F002 0
3505 RTD Input 22 Value -32768 to 32767 °C 1 F002 0
3506 RTD Input 23 Value -32768 to 32767 °C 1 F002 0
3507 RTD Input 24 Value -32768 to 32767 °C 1 F002 0
3508 RTD Input 25 Value -32768 to 32767 °C 1 F002 0
3509 RTD Input 26 Value -32768 to 32767 °C 1 F002 0
350A RTD Input 27 Value -32768 to 32767 °C 1 F002 0
350B RTD Input 28 Value -32768 to 32767 °C 1 F002 0
350C RTD Input 29 Value -32768 to 32767 °C 1 F002 0
350D RTD Input 30 Value -32768 to 32767 °C 1 F002 0
350E RTD Input 31 Value -32768 to 32767 °C 1 F002 0
350F RTD Input 32 Value -32768 to 32767 °C 1 F002 0
Table B–10: MODBUS MEMORY MAP (Sheet 12 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
