GE G60

GE Multilin G60 Generator Protection System B-21
APPENDIX B B.4 MEMORY MAPPING
B
3510 RTD Input 33 Value -32768 to 32767 °C 1 F002 0
3511 RTD Input 34 Value -32768 to 32767 °C 1 F002 0
3512 RTD Input 35 Value -32768 to 32767 °C 1 F002 0
3513 RTD Input 36 Value -32768 to 32767 °C 1 F002 0
3514 RTD Input 37 Value -32768 to 32767 °C 1 F002 0
3515 RTD Input 38 Value -32768 to 32767 °C 1 F002 0
3516 RTD Input 39 Value -32768 to 32767 °C 1 F002 0
3517 RTD Input 40 Value -32768 to 32767 °C 1 F002 0
3518 RTD Input 41 Value -32768 to 32767 °C 1 F002 0
3519 RTD Input 42 Value -32768 to 32767 °C 1 F002 0
351A RTD Input 43 Value -32768 to 32767 °C 1 F002 0
351B RTD Input 44 Value -32768 to 32767 °C 1 F002 0
351C RTD Input 45 Value -32768 to 32767 °C 1 F002 0
351D RTD Input 46 Value -32768 to 32767 °C 1 F002 0
351E RTD Input 47 Value -32768 to 32767 °C 1 F002 0
351F RTD Input 48 Value -32768 to 32767 °C 1 F002 0
Ohm Input Values (Read Only) (2 modules)
3520 Ohm Inputs 1 Value 0 to 65535 Ohm 1 F001 0
3521 Ohm Inputs 2 Value 0 to 65535 Ohm 1 F001 0
Expanded Direct Input/Output Status (Read Only)
3560 Direct Device States, one per register (16 items) 0 to 1 --- 1 F155 0 (Offline)
3570 Direct Input States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
RADIUS Configuration (Read/Write Setting)
3735 Undefined 0 to 4294967295 --- 1 F003 0
3737 Undefined 1 to 65535 --- 1 F001 1812
3738 Undefined 1 to 65535 --- 1 F001 1813
3739 Undefined 0 to 4294967295 --- 1 F003 0
373B Undefined 0 to 65535 --- 1 F001 1812
373D Undefined 0 to 65535 --- 1 F001 1813
373F Undefined --- --- 1 F619 0 (EAP-TTLS)
3740 Undefined 1 to 65535 --- 1 F001 2910
3741 Undefined 0 to 9999 sec 1 F001 10
3742 Undefined 0 to 9999 --- 1 F001 3
3743 Undefined --- --- --- F202 (none)
PTP Basic Configuration (Read/Write Setting)
3750 PTP Strict Power Profile 0 to 1 --- 1 F102 1 (Enabled)
3751 PTP Domain Number 0 to 255 --- 1 F001 0
3752 PTP VLAN Priority 0 to 7 --- 1 F001 4
3753 PTP VLAN ID 0 to 4095 --- 1 F001 0
3754 Undefined (2 items) 0 to 1 --- 1 F001 0
PTP Port Configuration (Read/Write Setting) (3 modules)
3756 PTP Port 1 Function 0 to 1 --- 1 F102 0 (Disabled)
3757 PTP Port 1 Path Delay Adder 0 to 60000 ns 1 F001 0
3758 PTP Port 1 Path Delay Asymmetry -1000 to 1000 ns 1 F002 0
3759 ...Repeated for PTP Port 2
375C ...Repeated for PTP Port 3
Real Time Clock Synchronizing Actual Values (Read Only)
375F RTC Sync Source 0 to 5 --- 1 F624 0 (None)
3760 PTP GrandMaster ID 0 to 100 -- 1 F073 0
3764 Real Time Clock Accuracy 0 to 999999999 ns 1 F003 0
3766 PTP Port 1 State (3 items) 0 to 4 -- 1 F625 0 (Disabled)
3769 RTC Offset 0 to 999999999 ns 1 F004 0
376B PTP - IRIG-B Delta -500000000 to 500000000 ns 1 F004 0
Table B–10: MODBUS MEMORY MAP (Sheet 13 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
