GE G60

B-22 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
Real Time Clock Synchronizing FlexAnalogs (Read Only)
376D PTP - IRIG-B Delta FlexAnalog -262143 to 262143 --- 1 F004 0
Frequency Out-of-Band Accumulation Actual Values (Read Only)
37A0 Frequency OOB Accumulator Band 1 Accumulation 0.0 to 999.9 % 0.1 F001 0
37A1 Frequency OOB Accumulator Band 2 Accumulation 0.0 to 999.9 % 0.1 F001 0
37A2 Frequency OOB Accumulator Band 3 Accumulation 0.0 to 999.9 % 0.1 F001 0
37A3 Frequency OOB Accumulator Band 4 Accumulation 0.0 to 999.9 % 0.1 F001 0
37A4 Frequency OOB Accumulator Band 5 Accumulation 0.0 to 999.9 % 0.1 F001 0
37A5 Frequency OOB Accumulator Band 6 Accumulation 0.0 to 999.9 % 0.1 F001 0
37A6 Frequency OOB Accumulator Band 7 Accumulation 0.0 to 999.9 % 0.1 F001 0
Frequency Out-of-Band Accumulation Commands (Read/Write)
37A7 Reset Frequency Out-Of-Band Accumulators 0 to 1 --- 1 F126 0 (No)
37A8 Preset Frequency Out-Of-Band Accumulators 0 to 1 --- 1 F126 0 (No)
Field Units (Read/Write Setting) (8 modules)
3800 Field Unit 1 ID 0 to 1 --- 1 F205 "U1"
3806 Field Unit 1 Function 0 to 1 --- 1 F102 0 (Disabled)
3807 Field Unit 1 Type 0 to 3 --- 1 F243 0 (CC-05)
3808 Field Unit 1 Serial Number 0 to1 --- 1 F205 "000000000000"
380E Field Unit 1 Port 1 to 4 --- 1 F001 1
380F ...Repeated for Field Unit 2
381E ...Repeated for Filed Unit 3
382D ...Repeated for Filed Unit 4
383C ...Repeated for Filed Unit 5
384B ...Repeated for Filed Unit 6
385A ...Repeated for Filed Unit 7
3869 ...Repeated for Filed Unit 8
Field Unit Process Card Ports (Read/Write Setting)
3878 Field Unit 1 Process Card Port 0 to 7 --- 1 F244 6 (H1a)
3879 Field Unit 2 Process Card Port 0 to 7 --- 1 F244 4 (H2a)
387A Field Unit3 Process Card Port 0 to 7 --- 1 F244 2 (H3a)
387B Field Unit 4 Process Card Port 0 to 7 --- 1 F244 0 (H4a)
387C Field Unit 5 Process Card Port 0 to 7 --- 1 F244 7 (H1b)
387D Field Unit 6 Process Card Port 0 to 7 --- 1 F244 5 (H2b)
387E Field Unit 7 Process Card Port 0 to 7 --- 1 F244 3 (H3b)
387F Field Unit 8 Process Card Port 0 to 7 --- 1 F244 1 (H4b)
Field Unit CT VT Settings (Read/Write Setting) (6 modules)
3890 Remote Phase CT x Origin 1 0 to 16 --- 1 F247 0 (None)
3891 Remote Phase CT x Origin 2 0 to 16 --- 1 F247 0 (None)
3892 Remote Ground CT x Origin 1 0 to 16 --- 1 F248 0 (None)
3893 Remote Ground CT x Origin 2 0 to 16 --- 1 F248 0 (None)
3894 AC Bank Redundancy Type 0 to 2 --- 1 F261 1 (Dependability
Biased)
3895 Remote Phase CT 1 Primary 1 to 65000 --- 1 F001 1
3896 Remote Phase CT 1 Secondary 0 to 1 --- 1 F123 0 (1 A)
3897 Remote Ground CT 1 Primary 1 to 65000 --- 1 F001 1
3898 Remote Ground CT 1 Secondary 0 to 1 --- 1 F123 0 (1 A)
3899 Remote Phase VT 1 Connection 0 to 1 --- 1 F100 0 (Wye)
389A Remote Phase VT 1 Secondary 25 to 240 --- 0.1 F001 664
389B Remote Phase VT 1 Ratio 1 to 24000 --- 1 F060 1
389D Remote Auxiliary VT 1 Connection 0 to 6 --- 1 F166 1 (Vag)
389E Remote Auxiliary VT 1 Secondary 25 to 240 --- 0.1 F001 664
389F Remote Auxiliary VT 1 Ratio 1 to 24000 --- 1 F060 1
38A1 ...Repeated for module number 2
38B2 ...Repeated for module number 3
Table B–10: MODBUS MEMORY MAP (Sheet 14 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
