B.4 MEMORY MAPPING APPENDIX B
B
411C IEC Communications Reserved (33 items) 0 to 1 --- 1 F001 0
413E High Enet Traffic Function 0 to 1 --- 1 F102 0 (Disabled)
413F High Enet Traffic Events 0 to 1 --- 1 F102 0 (Disabled)
4140 DNP Object 1 Default Variation 1 to 2 --- 1 F001 2
4141 DNP Object 2 Default Variation 1 to 3 --- 1 F001 2
4142 DNP Object 20 Default Variation 0 to 3 --- 1 F523 0 (1)
4143 DNP Object 21 Default Variation 0 to 3 --- 1 F524 0 (1)
4144 DNP Object 22 Default Variation 0 to 3 --- 1 F523 0 (1)
4145 DNP Object 23 Default Variation 0 to 3 --- 1 F523 0 (1)
4146 DNP Object 30 Default Variation 1 to 5 --- 1 F001 1
4147 DNP Object 32 Default Variation 0 to 5 --- 1 F525 0 (1)
Ethernet Switch (Read/Write Setting)
4148 Ethernet Switch IP Address 0 to 4294967295 --- 1 F003 3232235778
414A Ethernet Switch Modbus IP Port Number 1 to 65535 --- 1 F001 502
414B Ethernet Switch Port 1 Events 0 to 1 --- 1 F102 0 (Disabled)
414C Ethernet Switch Port 2 Events 0 to 1 --- 1 F102 0 (Disabled)
414D Ethernet Switch Port 3 Events 0 to 1 --- 1 F102 0 (Disabled)
414E Ethernet Switch Port 4 Events 0 to 1 --- 1 F102 0 (Disabled)
414F Ethernet Switch Port 5 Events 0 to 1 --- 1 F102 0 (Disabled)
4150 Ethernet Switch Port 6 Events 0 to 1 --- 1 F102 0 (Disabled)
Ethernet Switch Actual Values (Read Only)
4151 Ethernet Switch MAC Address --- --- --- F072 0
4154 Ethernet Switch Port 1 Status 0 to 2 --- 1 F134 0 (Fail)
4155 Ethernet Switch Port 2 Status 0 to 2 --- 1 F134 0 (Fail)
4156 Ethernet Switch Port 3 Status 0 to 2 --- 1 F134 0 (Fail)
4157 Ethernet Switch Port 4 Status 0 to 2 --- 1 F134 0 (Fail)
4158 Ethernet Switch Port 5 Status 0 to 2 --- 1 F134 0 (Fail)
4159 Ethernet Switch Port 6 Status 0 to 2 --- 1 F134 0 (Fail)
415A Switch Firmware Version 0.00 to 99.99 --- 0.01 F001 0
Communications Actual Values (Read Only)
4160 Modbus Available TCP/IP Connections 0 to 4 --- 1 F001 4
4161 DNP Available TCP/IP Connections 0 to 2 --- 1 F001 2
4162 IEC Available TCP/IP Connections 0 to 2 --- 1 F001 2
4163 MMS Available TCP/IP Connections 0 to 5 --- 1 F001 5
4164 PMU Available TCP/IP Connections 0 to 4 --- 1 F001 4
Simple Network Time Protocol (Read/Write Setting)
4168 Simple Network Time Protocol (SNTP) Function 0 to 1 --- 1 F102 0 (Disabled)
4169 Simple Network Time Protocol (SNTP) Server IP Address 0 to 4294967295 --- 1 F003 0
416B Simple Network Time Protocol (SNTP) UDP Port Number 1 to 65535 --- 1 F001 123
Data Logger Commands (Read/Write Command)
4170 Data Logger Clear 0 to 1 --- 1 F126 0 (No)
Data Logger (Read/Write Setting)
4181 Data Logger Channel Settings (16 items) --- --- --- F600 0
4191 Data Logger Mode 0 to 1 --- 1 F260 0 (Continuous)
4192 Data Logger Trigger 0 to 4294967295 --- 1 F300 0
4194 Data Logger Rate 15 to 3600000 ms 1 F003 60000
Clock (Read/Write Setting)
419F Synchronizing Source 0 to 3 --- 1 F623 0 (None)
Clock (Read/Write Command)
41A0 Real Time Clock Set Time 0 to 235959 --- 1 F050 0
Clock (Read/Write Setting)
41A2 SR Date Format 0 to 4294967295 --- 1 F051 0
41A4 SR Time Format 0 to 4294967295 --- 1 F052 0
41A6 IRIG-B Signal Type 0 to 2 --- 1 F114 0 (None)
Table B–10: MODBUS MEMORY MAP (Sheet 20 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
