GE Multilin G60 Generator Protection System B-29
APPENDIX B B.4 MEMORY MAPPING
B
41A7 Clock Events Enable / Disable 0 to 1 --- 1 F102 0 (Disabled)
41A8 Time Zone Offset from UTC –24 to 24 hours 0.5 F002 0
41A9 Daylight Savings Time (DST) Function 0 to 1 --- 1 F102 0 (Disabled)
41AA Daylight Savings Time (DST) Start Month 0 to 11 --- 1 F237 0 (January)
41AB Daylight Savings Time (DST) Start Day 0 to 6 --- 1 F238 0 (Sunday)
41AC Daylight Savings Time (DST) Start Day Instance 0 to 4 --- 1 F239 0 (First)
41AD Daylight Savings Time (DST) Start Hour 0 to 23 --- 1 F001 2
41AE Daylight Savings Time (DST) Stop Month 0 to 11 --- 1 F237 0 (January)
41AF Daylight Savings Time (DST) Stop Day 0 to 6 --- 1 F238 0 (Sunday)
41B0 Daylight Savings Time (DST) Stop Day Instance 0 to 4 --- 1 F239 0 (First)
41B1 Daylight Savings Time (DST) Stop Hour 0 to 23 --- 1 F001 2
Oscillography (Read/Write Setting)
41C0 Oscillography Number of Records 3 to 64 --- 1 F001 5
41C1 Oscillography Trigger Mode 0 to 1 --- 1 F118 0 (Auto.
Overwrite)
41C2 Oscillography Trigger Position 0 to 100 % 1 F001 50
41C3 Oscillography Trigger Source 0 to 4294967295 --- 1 F300 0
41C5 Oscillography AC Input Waveforms 0 to 4 --- 1 F183 2 (16 samples/
cycle)
41D0 Oscillography Analog Channel n (16 items) 0 to 65535 --- 1 F600 0
4200 Oscillography Digital Channel n (63 items) 0 to 4294967295 --- 1 F300 0
Trip and Alarm LEDs (Read/Write Setting)
42B0 Trip LED Input FlexLogic Operand 0 to 4294967295 --- 1 F300 0
42B2 Alarm LED Input FlexLogic Operand 0 to 4294967295 --- 1 F300 0
User Programmable LEDs (Read/Write Setting) (48 modules)
42C0 FlexLogic Operand to Activate LED 0 to 4294967295 --- 1 F300 0
42C2 User LED type (latched or self-resetting) 0 to 1 --- 1 F127 1 (Self-Reset)
42C3 ...Repeated for User-Programmable LED 2
42C6 ...Repeated for User-Programmable LED 3
42C9 ...Repeated for User-Programmable LED 4
42CC ...Repeated for User-Programmable LED 5
42CF ...Repeated for User-Programmable LED 6
42D2 ...Repeated for User-Programmable LED 7
42D5 ...Repeated for User-Programmable LED 8
42D8 ...Repeated for User-Programmable LED 9
42DB ...Repeated for User-Programmable LED 10
42DE ...Repeated for User-Programmable LED 11
42E1 ...Repeated for User-Programmable LED 12
42E4 ...Repeated for User-Programmable LED 13
42E7 ...Repeated for User-Programmable LED 14
42EA ...Repeated for User-Programmable LED 15
42ED ...Repeated for User-Programmable LED 16
42F0 ...Repeated for User-Programmable LED 17
42F3 ...Repeated for User-Programmable LED 18
42F6 ...Repeated for User-Programmable LED 19
42F9 ...Repeated for User-Programmable LED 20
42FC ...Repeated for User-Programmable LED 21
42FF ...Repeated for User-Programmable LED 22
4302 ...Repeated for User-Programmable LED 23
4305 ...Repeated for User-Programmable LED 24
4308 ...Repeated for User-Programmable LED 25
430B ...Repeated for User-Programmable LED 26
430E ...Repeated for User-Programmable LED 27
4311 ...Repeated for User-Programmable LED 28
4314 ...Repeated for User-Programmable LED 29
Table B–10: MODBUS MEMORY MAP (Sheet 21 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
