GE Multilin G60 Generator Protection System B-35
APPENDIX B B.4 MEMORY MAPPING
B
5898 ...Repeated for FlexLogic Timer 20
58A0 ...Repeated for FlexLogic Timer 21
58A8 ...Repeated for FlexLogic Timer 22
58B0 ...Repeated for FlexLogic Timer 23
58B8 ...Repeated for FlexLogic Timer 24
58C0 ...Repeated for FlexLogic Timer 25
58C8 ...Repeated for FlexLogic Timer 26
58D0 ...Repeated for FlexLogic Timer 27
58D8 ...Repeated for FlexLogic Timer 28
58E0 ...Repeated for FlexLogic Timer 29
58E8 ...Repeated for FlexLogic Timer 30
58F0 ...Repeated for FlexLogic Timer 31
58F8 ...Repeated for FlexLogic Timer 32
Phase Time Overcurrent (Read/Write Grouped Setting)
5900 Phase Time Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5901 Phase Time Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
5902 Phase Time Overcurrent 1 Input 0 to 1 --- 1 F122 0 (Phasor)
5903 Phase Time Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
5904 Phase Time Overcurrent 1 Curve 0 to 16 --- 1 F103 0 (IEEE Mod Inv)
5905 Phase Time Overcurrent 1 Multiplier 0 to 600 --- 0.01 F001 100
5906 Phase Time Overcurrent 1 Reset 0 to 1 --- 1 F104 0 (Instantaneous)
5907 Phase Time Overcurrent 1 Voltage Restraint 0 to 1 --- 1 F102 0 (Disabled)
5908 Phase TOC 1 Block For Each Phase (3 items) 0 to 4294967295 --- 1 F300 0
590F Phase Time Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
5910 Phase Time Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
5911 Reserved (3 items) 0 to 1 --- 1 F001 0
Phase Instantaneous Overcurrent (Read/Write Grouped Setting) (2 modules)
5A00 Phase Instantaneous Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5A01 Phase Instantaneous Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
5A02 Phase Instantaneous Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
5A03 Phase Instantaneous Overcurrent 1 Delay 0 to 600 s 0.01 F001 0
5A04 Phase Instantaneous Overcurrent 1 Reset Delay 0 to 600 s 0.01 F001 0
5A05 Phase IOC1 Block For Each Phase (3 items) 0 to 4294967295 --- 1 F300 0
5A0B Phase Instantaneous Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
5A0C Phase Instantaneous Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
5A0D Reserved (6 items) 0 to 1 --- 1 F001 0
5A13 ...Repeated for Phase Instantaneous Overcurrent 2
Neutral Time Overcurrent (Read/Write Grouped Setting)
5B00 Neutral Time Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5B01 Neutral Time Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
5B02 Neutral Time Overcurrent 1 Input 0 to 1 --- 1 F122 0 (Phasor)
5B03 Neutral Time Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
5B04 Neutral Time Overcurrent 1 Curve 0 to 16 --- 1 F103 0 (IEEE Mod Inv)
5B05 Neutral Time Overcurrent 1 Multiplier 0 to 600 --- 0.01 F001 100
5B06 Neutral Time Overcurrent 1 Reset 0 to 1 --- 1 F104 0 (Instantaneous)
5B07 Neutral Time Overcurrent 1 Block 0 to 4294967295 --- 1 F300 0
5B09 Neutral Time Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
5B0A Neutral Time Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
5B0B Reserved (6 items) 0 to 1 --- 1 F001 0
Neutral Instantaneous Overcurrent (Read/Write Grouped Setting)
5C00 Neutral Instantaneous Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5C01 Neutral Instantaneous Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
5C02 Neutral Instantaneous Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
5C03 Neutral Instantaneous Overcurrent 1 Delay 0 to 600 s 0.01 F001 0
Table B–10: MODBUS MEMORY MAP (Sheet 27 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
