GE G60

B-38 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
647D ...Repeated for Overfrequency 2
648A ...Repeated for Overfrequency 3
6497 ...Repeated for Overfrequency 4
Power Swing Detect (Read/Write Grouped Setting)
65C0 Power Swing Detect Function 0 to 1 --- 1 F102 0 (Disabled)
65C1 Power Swing Detect Source 0 to 5 --- 1 F167 0 (SRC 1)
65C2 Power Swing Detect Mode 0 to 1 --- 1 F513 0 (Two Step)
65C3 Power Swing Detect Supervision 0.05 to 30 pu 0.001 F001 600
65C4 Power Swing Detect Forward Reach 0.1 to 500 ohms 0.01 F001 5000
65C5 Power Swing Detect Forward RCA 40 to 90 degrees 1 F001 75
65C6 Power Swing Detect Reverse Reach 0.1 to 500 ohms 0.01 F001 5000
65C7 Power Swing Detect Reverse RCA 40 to 90 degrees 1 F001 75
65C8 Power Swing Detect Outer Limit Angle 40 to 140 degrees 1 F001 120
65C9 Power Swing Detect Middle Limit Angle 40 to 140 degrees 1 F001 90
65CA Power Swing Detect Inner Limit Angle 40 to 140 degrees 1 F001 60
65CB Power Swing Detect Delay 1 Pickup 0 to 65.535 s 0.001 F001 30
65CC Power Swing Detect Delay 1 Reset 0 to 65.535 s 0.001 F001 50
65CD Power Swing Detect Delay 2 Pickup 0 to 65.535 s 0.001 F001 17
65CE Power Swing Detect Delay 3 Pickup 0 to 65.535 s 0.001 F001 9
65CF Power Swing Detect Delay 4 Pickup 0 to 65.535 s 0.001 F001 17
65D0 Power Swing Detect Seal In Delay 0 to 65.535 s 0.001 F001 400
65D1 Power Swing Detect Trip Mode 0 to 1 --- 1 F514 0 (Delayed)
65D2 Power Swing Detect Block 0 to 4294967295 --- 1 F300 0
65D4 Power Swing Detect Target 0 to 2 --- 1 F109 0 (Self-reset)
65D5 Power Swing Detect Event 0 to 1 --- 1 F102 0 (Disabled)
65D6 Power Swing Detect Shape 0 to 1 --- 1 F085 0 (Mho Shape)
65D7 Power Swing Detect Quad Forward Middle 0.1 to 500 ohms 0.01 F001 6000
65D8 Power Swing Detect Quad Forward Outer 0.1 to 500 ohms 0.01 F001 7000
65D9 Power Swing Detect Quad Reverse Middle 0.1 to 500 ohms 0.01 F001 6000
65DA Power Swing Detect Quad Reverse Outer 0.1 to 500 ohms 0.01 F001 7000
65DB Power Swing Detect Outer Right Blinder 0.1 to 500 ohms 0.01 F001 10000
65DC Power Swing Detect Outer Left Blinder 0.1 to 500 ohms 0.01 F001 10000
65DD Power Swing Detect Middle Right Blinder 0.1 to 500 ohms 0.01 F001 10000
65DE Power Swing Detect Middle Left Blinder 0.1 to 500 ohms 0.01 F001 10000
65DF Power Swing Detect Inner Right Blinder 0.1 to 500 ohms 0.01 F001 10000
65E0 Power Swing Detect Inner Left Blinder 0.1 to 500 ohms 0.01 F001 10000
Field Ground Actual Values (Read Only)
6640 Field Ground Resistance 0 to 20000 KOhm 0.001 F003 20000000
6642 Field Ground Current 0 to 655.35 mA 0.01 F001 0
6643 Field Ground Injected Voltage -32.767 to 32.767 V 0.001 F002 0
6644 Field Ground Fault Location -30000 to 30000 % 1 F002 -10
6645 Field Ground Field Voltage -3276.8 to 3276.7 V 0.1 F002 0
6646 Field Current -9999.999 to 9999.999 --- 0.001 F004 0
6648 Field Current Units --- --- --- F206 "A"
Accidental Energization (Read/Write Grouped Setting)
6650 Accidental Energization Function 0 to 1 --- 1 F102 0 (Disabled)
6651 Accidental Energization Source 0 to 5 --- 1 F167 0 (SRC 1)
6652 Accidental Energization Arming Mode 0 to 1 --- 1 F193 0 (UV AND
OFFLINE)
6653 Accidental Energization OC Pickup 0 to 3 --- 0.001 F003 300
6655 Accidental Energization UV Pickup 0 to 3 --- 0.001 F003 500
6657 Accidental Energization Offline 0 to 4294967295 --- 1 F300 0
6659 Accidental Energization Block 0 to 4294967295 --- 1 F300 0
665B Accidental Energization Target 0 to 2 --- 1 F109 0 (Self-reset)
Table B–10: MODBUS MEMORY MAP (Sheet 30 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
