GE G60

GE Multilin G60 Generator Protection System B-39
APPENDIX B B.4 MEMORY MAPPING
B
665C Accidental Energization Events 0 to 1 --- 1 F102 0 (Disabled)
665D Reserved (5 items) 0 to 65535 --- 1 F001 0
Loss of Excitation (Read/Write Grouped Setting)
666A Loss Of Excitation Function 0 to 1 --- 1 F102 0 (Disabled)
666B Loss Of Excitation Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
666C Loss Of Excitation Center 1 0.1 to 300 ohm 0.01 F001 1000
666D Loss Of Excitation Radius 1 0.1 to 300 ohm 0.01 F001 800
666E Loss Of Excitation UV Supervision Enable 1 0 to 1 --- 1 F102 1 (Enabled)
666F Loss Of Excitation Pickup Delay 1 0 to 65.535 s 0.001 F001 50
6670 Loss Of Excitation Center 2 0.1 to 300 ohm 0.01 F001 1200
6671 Loss Of Excitation Radius 2 0.1 to 300 ohm 0.01 F001 1000
6672 Loss Of Excitation UV Supervision Enable 2 0 to 1 --- 1 F102 1 (Enabled)
6673 Loss Of Excitation Pickup Delay 2 0 to 65.535 s 0.001 F001 500
6674 Loss Of Excitation UV Supervision 0 to 1.25 pu 0.001 F001 700
6675 Loss Of Excitation Block 0 to 4294967295 --- 1 F300 0
6677 Loss Of Excitation Target 0 to 2 --- 1 F109 0 (Self-reset)
6678 Loss Of Excitation Events 0 to 1 --- 1 F102 0 (Disabled)
6679 Reserved (5 items) 0 to 65535 --- 1 F001 0
Sensitive Directional Power (Read/Write Grouped Setting) (2 modules)
6680 Sensitive Directional Power 1 Function 0 to 1 --- 1 F102 0 (Disabled)
6681 Sensitive Directional Power 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
6682 Sensitive Directional Power 1 RCA 0 to 359 degrees 1 F001 0
6683 Sensitive Directional Power 1 Calibration 0 to 0.95 degrees 0.05 F001 0
6684 Sensitive Directional Power 1 STG1 SMIN -1.2 to 1.2 pu 0.001 F002 100
6685 Sensitive Directional Power 1 STG1 Delay 0 to 600 s 0.01 F001 50
6686 Sensitive Directional Power 1 STG2 SMIN -1.2 to 1.2 pu 0.001 F002 100
6687 Sensitive Directional Power 1 STG2 Delay 0 to 600 s 0.01 F001 2000
6688 Sensitive Directional Power 1 Block 0 to 4294967295 --- 1 F300 0
668A Sensitive Directional Power 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
668B Sensitive Directional Power 1 Events 0 to 1 --- 1 F102 0 (Disabled)
668C Reserved (5 items) 0 to 65535 --- 1 F001 0
6691 ...Repeated for Sensitive Directional Power 2
Third Harmonic Neutral Undervoltage (Read/Write Grouped Setting)
66DA Third Harmonic Neutral Undervoltage Function 0 to 1 --- 1 F102 0 (Disabled)
66DB Third Harmonic Neutral Undervoltage Pickup 0 to 30 pu 0.0001 F003 3000
66DD Third Harmonic Neutral Undervoltage Delay 0 to 600 s 0.01 F001 0
66DE Third Harmonic Neutral Undervoltage Max Power 0 to 30 pu 0.001 F003 200
66E0 Third Harmonic Neutral Undervoltage Min Power 0 to 30 pu 0.001 F003 200
66E2 Third Harmonic Neutral Undervoltage Volt Supervision 0 to 1.25 pu 0.001 F001 500
66E3 Third Harmonic Neutral Undervoltage Block 0 to 4294967295 --- 1 F300 0
66E5 Third Harmonic Neutral Undervoltage Target 0 to 2 --- 1 F109 0 (Self-reset)
66E6 Third Harmonic Neutral Undervoltage Events 0 to 1 --- 1 F102 0 (Disabled)
66E7 Reserved (4 items) 0 to 65535 --- 1 F001 0
Generator Unbalance (Read/Write Grouped Setting)
66F0 Generator Unbalance Function 0 to 1 --- 1 F102 0 (Disabled)
66F1 Generator Unbalance Source 0 to 5 --- 1 F167 0 (SRC 1)
66F2 Generator Unbalance Inom 0 to 1.25 pu 0.001 F001 800
66F3 Generator Unbalance Stage 1 Pickup 0 to 100 % 0.01 F001 800
66F4 Generator Unbalance Stage 1 K value 0 to 100 --- 0.01 F001 100
66F5 Generator Unbalance Stage 1 Tmin 0 to 50 s 0.001 F001 250
66F6 Generator Unbalance Stage 1 Tmax 0 to 1000 s 0.1 F001 6000
66F7 Generator Unbalance Stage 1 K Reset 0 to 1000 s 0.1 F001 2400
66F8 Generator Unbalance Stage 2 Pickup 0 to 100 % 0.01 F001 300
66F9 Generator Unbalance Stage 2 Pickup Delay 0 to 1000 s 0.1 F001 50
Table B–10: MODBUS MEMORY MAP (Sheet 31 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
