GE G60

B-40 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
66FA Generator Unbalance Block 0 to 4294967295 --- 1 F300 0
66FC Generator Unbalance Target 0 to 2 --- 1 F109 0 (Self-reset)
66FD Generator Unbalance Events 0 to 1 --- 1 F102 0 (Disabled)
66FE Reserved (3 items) 0 to 65535 --- 1 F001 0
Stator Ground Source (Read/Write Grouped Setting)
670A Stator Ground Source 0 to 5 --- 1 F167 0 (SRC 1)
Subharmonic Stator Ground (Read/Write Grouped Setting)
6710 Subharmonic Stator Ground Function 0 to 1 --- 1 F102 0 (Disabled)
6711 Subharmonic Stator Ground Stage 1 Pickup 1 to 20 kOhm 1 F001 10
6712 Subharmonic Stator Ground Stage 1 Pickup Delay 0.1 to 600 s 0.1 F001 100
6713 Subharmonic Stator Ground Stage 2 Pickup 1 to 20 kOhm 1 F001 3
6714 Subharmonic Stator Ground Stage 2 Pickup Delay 0.1 to 600 s 0.1 F001 10
6715 Subharmonic CT Angle Compensation -30 to 30 degrees 0.1 F002 0
6718 Subharmonic Stator Ground OC Pickup 0.001 to 1 pu 0.001 F001 10
6719 Subharmonic Stator Ground OC Delay 0.1 to 600 s 0.01 F001 100
671A Subharmonic Stator Ground Volt Supv 0 to 0.1 pu 0.001 F001 0
671B Subharmonic Stator Ground Curr Supv 0 to 0.1 pu 0.001 F001 0
671C Subharmonic Stator Ground Block 0 to 4294967295 --- --- F300 0
671E Subharmonic Stator Ground Events 0 to 1 --- 1 F102 0 (Disabled)
671F Subharmonic Stator Ground Target 0 to 2 --- 1 F109 0 (Self-reset)
Stator Ground (Read/Write Grouped Setting)
6720 Stator Ground Function 0 to 1 --- 1 F102 0 (Disabled)
6721 Stator Ground Stage 1 Pickup 0 to 0.9 pu 0.001 F001 150
6722 Stator Ground Stage 1 Pickup Delay 0 to 600 s 0.01 F001 100
6723 Stator Ground Stage 1 Supv 0.001 to 0.1 pu 0.0001 F001 57
6724 Stator Ground Stage 2 Pickup 0 to 0.9 pu 0.001 F001 150
6725 Stator Ground Stage 2 Pickup Delay 0 to 600 s 0.01 F001 0
6726 Stator Ground Stage 2 Supv 0.001 to 0.1 pu 0.0001 F001 45
6727 Stator Ground Block 0 to 4294967295 --- 1 F300 0
6729 Stator Ground Target 0 to 2 --- 1 F109 0 (Self-reset)
672A Stator Ground Event 0 to 1 --- 1 F102 0 (Disabled)
672B Reserved (5 items) 0 to 65535 --- 1 F001 0
Split Phase Protection (Read/Write Grouped Setting)
6730 Split Phase Protection Function 0 to 1 --- 1 F102 0 (Disabled)
6731 Split Phase Protection Source 0 to 5 --- 1 F167 0 (SRC1)
6732 Split Phase Protection Load Source 0 to 5 --- 1 F167 0 (SRC1)
6733 Split Phase Protection Phase A Pickup 0.02 to 1.500 pu 0.001 F001 200
6734 Split Phase Protection Phase A Offset 0 to 1 pu 0.001 F001 0
6735 Split Phase Protection Phase A Slope 0 to 100 % 0.1 F001 0
6736 Split Phase Protection Phase B Pickup 0.02 to 1.500 pu 0.001 F001 200
6737 Split Phase Protection Phase B Offset 0 to 1 pu 0.001 F001 0
6738 Split Phase Protection Phase B Slope 0 to 100 % 0.1 F001 0
6739 Split Phase Protection Phase C Pickup 0.02 to 1.500 pu 0.001 F001 200
673A Split Phase Protection Phase C Offset 0 to 1 pu 0.001 F001 0
673B Split Phase Protection Phase C Slope 0 to 100 % 0.1 F001 0
673C Split Phase Protection Minimum Load 0 to 1 pu 0.01 F001 0
673D Split Phase Protection Mode 0 to 1 --- 1 F225 0 (Over)
673E Split Phase Protection Delay 0 to 65.535 s 0.001 F001 0
673F Split Phase Protection Block 0 to 4294967295 --- 1 F300 0
6741 Split Phase Protection Target 0 to 2 --- 1 F109 0 (Self-Reset)
6742 Split Phase Protection Events 0 to 1 --- 1 F102 0 (Disabled)
6743 Reserved (6 items) 0 to 65535 --- 1 F001 0
Phase Undervoltage (Read/Write Grouped Setting) (3 modules)
7000 Phase Undervoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
Table B–10: MODBUS MEMORY MAP (Sheet 32 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
