GE Multilin G60 Generator Protection System B-43
APPENDIX B B.4 MEMORY MAPPING
B
74B5 Disconnect Switch 1 Phase C Closed 0 to 4294967295 --- 1 F300 0
74B7 Disconnect Switch 1 Phase C Opened 0 to 4294967295 --- 1 F300 0
74B9 Disconnect Switch 1 Operate Time 0 to 65.535 s 0.001 F001 70
74BA Disconnect Switch 1 Alarm Delay 0 to 65.535 s 0.001 F003 0
74BC Disconnect Switch 1 Events 0 to 1 --- 1 F102 0 (Disabled)
74BD Reserved (2 items) --- --- --- F001 0
74BF ...Repeated for Disconnect Switch 2
74DE ...Repeated for Disconnect Switch 3
74FD ...Repeated for Disconnect Switch 4
751C ...Repeated for Disconnect Switch 5
753B ...Repeated for Disconnect Switch 6
755A ...Repeated for Disconnect Switch 7
7579 ...Repeated for Disconnect Switch 8
7598 ...Repeated for Disconnect Switch 9
75B7 ...Repeated for Disconnect Switch 10
75D6 ...Repeated for Disconnect Switch 11
75F5 ...Repeated for Disconnect Switch 12
7614 ...Repeated for Disconnect Switch 13
7633 ...Repeated for Disconnect Switch 14
7652 ...Repeated for Disconnect Switch 15
Thermal Overload Protection (Read/Write Settings) (2 modules)
7788 Thermal Protection 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7789 Thermal Protection 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
778A Thermal Protection 1 Base Current 0.2 to 3 pu 0.01 F001 80
778B Thermal Protection 1 K Factor 1 to 1.2 --- 0.05 F001 110
778C Thermal Protection 1 Trip Time Constant 0 to 1000 min. 1 F001 45
778D Thermal Protection 1 Reset Time Constant 0 to 1000 min. 1 F001 45
778E Thermal Protection 1 Minimum Reset Time 0 to 1000 min. 1 F001 20
778F Thermal Protection 1 Reset 0 to 4294967295 --- 1 F300 0
7791 Thermal Protection 1 Block 0 to 4294967295 --- 1 F300 0
7793 Thermal Protection 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7794 Thermal Protection 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7795 Reserved (2 items) --- --- --- F001 0
7797 Repeated for Thermal Protection 2
Ohm Inputs (Read/Write Setting) (2 modules)
77F8 Ohm Inputs 1 Function 0 to 1 --- 1 F102 0 (Disabled)
77F9 Ohm Inputs 1 ID --- --- --- F205 "Ohm Ip 1 "
77FF Ohm Inputs 1 Reserved (9 items) 0 to 65535 --- 1 F001 0
7808 ...Repeated for Ohm Inputs 2
Phasor Measurement Unit Recorder Config Counter Command (Read/Write Command)
781A PMU 1 Recorder Clear Config Counter 0 to 1 --- 1 F126 0 (No)
Phasor Measurement Unit Power Trigger (Read/Write Setting)
7820 PMU 1 Power Trigger Function 0 to 1 --- 1 F102 0 (Disabled)
7821 PMU 1 Power Trigger Active 0.25 to 3 pu 0.001 F001 1250
7822 PMU 1 Power Trigger Reactive 0.25 to 3 pu 0.001 F001 1250
7823 PMU 1 Power Trigger Apparent 0.25 to 3 pu 0.001 F001 1250
7824 PMU 1 Power Trigger Pickup Time 0 to 600 s 0.01 F001 10
7825 PMU 1 Power Trigger Dropout Time 0 to 600 s 0.01 F001 100
7826 PMU 1 Power Trigger Block (3 items) 0 to 4294967295 --- 1 F300 0
782C PMU 1 Power Trigger Target 0 to 2 --- 1 F109 0 (Self-reset)
782D PMU 1 Power Trigger Events 0 to 1 --- 1 F102 0 (Disabled)
Phasor Measurement Unit Voltage Trigger (Read/Write Setting)
7858 PMU 1 Voltage Trigger Function 0 to 1 --- 1 F102 0 (Disabled)
7859 PMU 1 Voltage Trigger Low Voltage 0.25 to 1.25 pu 0.001 F001 800
Table B–10: MODBUS MEMORY MAP (Sheet 35 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
