B-44 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
785A PMU 1 Voltage Trigger High Voltage 0.75 to 1.75 pu 0.001 F001 1200
785B PMU 1 Voltage Trigger Pickup Time 0 to 600 s 0.01 F001 10
785C PMU 1 Voltage Trigger Dropout Time 0 to 600 s 0.01 F001 100
785D PMU 1 Voltage Trigger Block (3 items) 0 to 4294967295 --- 1 F300 0
7863 PMU 1 Voltage Trigger Target 0 to 2 --- 1 F109 0 (Self-reset)
7864 PMU 1 Voltage Trigger Events 0 to 1 --- 1 F102 0 (Disabled)
Phasor Measurement Unit One-shot Command (Read/Write Setting)
788C PMU One-shot Function 0 to 1 --- 1 F102 0 (Disabled)
788D PMU One-shot Sequence Number 0 to 99 --- 1 F001 1
788E PMU One-shot Time 0 to 235959 --- 1 F050 0
Phasor Measurement Unit Test Values (Read/Write Setting)
7890 PMU 1 Test Function 0 to 1 --- 1 F102 0 (Disabled)
7891 PMU 1 Phase A Voltage Test Magnitude 0 to 700 kV 0.01 F003 50000
7893 PMU 1 Phase A Voltage Test Angle -180 to 180 ° 0.05 F002 0
7894 PMU 1 Phase B Voltage Test Magnitude 0 to 700 kV 0.01 F003 50000
7896 PMU 1 Phase B Voltage Test Angle -180 to 180 ° 0.05 F002 -12000
7897 PMU 1 Phase C Voltage Test Magnitude 0 to 700 kV 0.01 F003 50000
7899 PMU 1 Phase C Voltage Test Angle -180 to 180 ° 0.05 F002 12000
789A PMU 1 Auxiliary Voltage Test Magnitude 0 to 700 kV 0.01 F003 50000
789C PMU 1 Auxiliary Voltage Test Angle -180 to 180 ° 0.05 F002 0
789D PMU 1 Phase A Current Test Magnitude 0 to 9.999 kA 0.001 F004 1000
789F PMU 1 Phase A Current Test Angle -180 to 180 ° 0.05 F002 -1000
78A0 PMU 1 Phase B Current Test Magnitude 0 to 9.999 kA 0.001 F004 1000
78A2 PMU 1 Phase B Current Test Angle -180 to 180 ° 0.05 F002 -13000
78A3 PMU 1 Phase C Current Test Magnitude 0 to 9.999 kA 0.001 F003 1000
78A5 PMU 1 Phase C Current Test Angle -180 to 180 ° 0.05 F002 11000
78A6 PMU 1 Ground Current Test Magnitude 0 to 9.999 kA 0.001 F004 0
78A8 PMU 1 Ground Current Test Angle -180 to 180 ° 0.05 F002 0
78A9 PMU 1 Test Frequency 20 to 70 Hz 0.001 F003 60000
78AB PMU 1 Test df/dt -10 to 10 Hz/s 0.01 F002 0
Phasor Measurement Unit Recording Values (Read Only)
7900 PMU 1 Available Records 0 to 65535 --- 1 F001 0
7901 PMU 1 Second Per Record 0 to 6553.5 --- 0.1 F003 0
7903 PMU 1 Last Cleared Date 0 to 400000000 --- 1 F050 0
Phasor Measurement Unit Network Reporting Configuration (Read/Write Setting)
7914 PMU Network Reporting Function 0 to 1 --- 1 F102 0 (Disabled)
7915 PMU Network Reporting ID Code 1 to 65534 --- 1 F001 1
7916 PMU TCP Port Number 1 to 65535 --- 1 F001 4712
7917 PMU UDP Port Number 1 1 to 65535 --- 1 F001 4713
7918 PMU UDP Port Number 2 1 to 65535 --- 1 F001 4714
Phasor Measurement Unit Calibration (Read/Write Setting)
7919 PMU 1 Va Calibration Angle -5 to 5 ° 0.05 F002 0
791A PMU 1 Va Calibration Magnitude 95 to 105 % 0.1 F002 1000
791B PMU 1 Vb Calibration Angle -5 to 5 ° 0.05 F002 0
791C PMU 1 Vb Calibration Magnitude 95 to 105 % 0.1 F002 1000
791D PMU 1 Vc Calibration Angle -5 to 5 ° 0.05 F002 0
791E PMU 1 Vc Calibration Magnitude 95 to 105 % 0.1 F002 1000
791F PMU 1 Vx Calibration Angle -5 to 5 ° 0.05 F002 0
7920 PMU 1 Vx Calibration Magnitude 95 to 105 % 0.1 F002 1000
7921 PMU 1 Ia Calibration Angle -5 to 5 ° 0.05 F002 0
7922 PMU 1 Ia Calibration Magnitude 95 to 105 % 0.1 F002 1000
7923 PMU 1 Ib Calibration Angle -5 to 5 ° 0.05 F002 0
7924 PMU 1 Ib Calibration Magnitude 95 to 105 % 0.1 F002 1000
7925 PMU 1 Ic Calibration Angle -5 to 5 ° 0.05 F002 0
Table B–10: MODBUS MEMORY MAP (Sheet 36 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
