GE G60

GE Multilin G60 Generator Protection System B-51
APPENDIX B B.4 MEMORY MAPPING
B
913B ...Repeated for FlexElement16
RRTD Inputs (Read/Write Setting) (12 modules)
9260 RRTD RTD 1 Function 0 to 1 --- 1 F102 0 (Disabled)
9261 RRTD RTD 1 ID --- --- --- F205 "RRTD 1 "
9267 RRTD RTD 1 Type 0 to 3 --- 1 F174 0 (100 Ohm
Platinum)
9268 RRTD RTD 1 Application 0 to 5 --- 1 F550 0 (None)
9269 RRTD RTD 1 Alarm Temp 1 to 200 °C 1 F001 130
926A RRTD RTD 1 Alarm Pickup Delay 5 to 600 s 5 F001 5
926B RRTD RTD 1 Trip Temp 1 to 200 °C 1 F001 130
926C RRTD RTD 1 Trip Pickup Delay 5 to 600 s 5 F001 5
926D RRTD RTD 1 Trip Reset Delay 5 to 600 s 5 F001 5
926E RRTD RTD 1 Trip Voting 0 to 13 --- 1 F603 0 (None)
926F RRTD RTD 1 Block 0 to 4294967295 --- 1 F300 0
9271 RRTD RTD 1 Open 0 to 2 --- 1 F552 0 (None)
9272 RRTD RTD 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
9273 RRTD RTD 1 Events 0 to 1 --- 1 F102 0 (Disabled)
9274 ...Repeated for module number 2
9288 ...Repeated for module number 3
929C ...Repeated for module number 4
92B0 ...Repeated for module number 5
92C4 ...Repeated for module number 6
92D8 ...Repeated for module number 7
92EC ...Repeated for module number 8
9300 ...Repeated for module number 9
9314 ...Repeated for module number 10
9328 ...Repeated for module number 11
933C ...Repeated for module number 12
DCmA Outputs (Read/Write Setting) (24 modules)
9360 DCmA Output 1 Source 0 to 65535 --- 1 F600 0
9361 DCmA Output 1 Range 0 to 2 --- 1 F522 0 (–1 to 1 mA)
9362 DCmA Output 1 Minimum –90 to 90 pu 0.001 F004 0
9364 DCmA Output 1 Maximum –90 to 90 pu 0.001 F004 1000
9366 ...Repeated for DCmA Output 2
936C ...Repeated for DCmA Output 3
9372 ...Repeated for DCmA Output 4
9378 ...Repeated for DCmA Output 5
937E ...Repeated for DCmA Output 6
9384 ...Repeated for DCmA Output 7
938A ...Repeated for DCmA Output 8
9390 ...Repeated for DCmA Output 9
9396 ...Repeated for DCmA Output 10
939C ...Repeated for DCmA Output 11
93A2 ...Repeated for DCmA Output 12
93A8 ...Repeated for DCmA Output 13
93AE ...Repeated for DCmA Output 14
93B4 ...Repeated for DCmA Output 15
93BA ...Repeated for DCmA Output 16
93C0 ...Repeated for DCmA Output 17
93C6 ...Repeated for DCmA Output 18
93CC ...Repeated for DCmA Output 19
93D2 ...Repeated for DCmA Output 20
93D8 ...Repeated for DCmA Output 21
93DE ...Repeated for DCmA Output 22
Table B–10: MODBUS MEMORY MAP (Sheet 43 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
