B.4 MEMORY MAPPING APPENDIX B
B
93E4 ...Repeated for DCmA Output 23
93EA ...Repeated for DCmA Output 24
Direct Input/Output Names (Read/Write Setting) (32 modules)
9400 Direct Input 1 Name 0 to 96 --- 1 F205 “Dir Ip 1”
9406 Direct Output 1 Name 1 to 96 --- 1 F205 “Dir Out 1”
940C ...Repeated for Direct Input/Output 2
9418 ...Repeated for Direct Input/Output 3
9424 ...Repeated for Direct Input/Output 4
9430 ...Repeated for Direct Input/Output 5
943C ...Repeated for Direct Input/Output 6
9448 ...Repeated for Direct Input/Output 7
9454 ...Repeated for Direct Input/Output 8
9460 ...Repeated for Direct Input/Output 9
946C ...Repeated for Direct Input/Output 10
9478 ...Repeated for Direct Input/Output 11
9484 ...Repeated for Direct Input/Output 12
9490 ...Repeated for Direct Input/Output 13
949C ...Repeated for Direct Input/Output 14
94A8 ...Repeated for Direct Input/Output 15
94B4 ...Repeated for Direct Input/Output 16
94C0 ...Repeated for Direct Input/Output 17
94CC ...Repeated for Direct Input/Output 18
94D8 ...Repeated for Direct Input/Output 19
94E4 ...Repeated for Direct Input/Output 20
94F0 ...Repeated for Direct Input/Output 21
94FC ...Repeated for Direct Input/Output 22
9508 ...Repeated for Direct Input/Output 23
9514 ...Repeated for Direct Input/Output 24
9520 ...Repeated for Direct Input/Output 25
952C ...Repeated for Direct Input/Output 26
9538 ...Repeated for Direct Input/Output 27
9544 ...Repeated for Direct Input/Output 28
9550 ...Repeated for Direct Input/Output 29
955C ...Repeated for Direct Input/Output 30
9568 ...Repeated for Direct Input/Output 31
9574 ...Repeated for Direct Input/Output 32
IEC 61850 Received Integers (Read/Write Setting) (16 modules)
98A0 IEC 61850 GOOSE uinteger 1 Default Value 0 to 429496295 --- 1 F003 1000
98A2 IEC 61850 GOOSE uinteger Input 1 Mode 0 to 1 --- 1 F491 0 (Default
Value)
98A3 ...Repeated for IEC61850 GOOSE uinteger 2
98A6 ...Repeated for IEC61850 GOOSE uinteger 3
98A9 ...Repeated for IEC61850 GOOSE uinteger 4
98AC ...Repeated for IEC61850 GOOSE uinteger 5
98AF ...Repeated for IEC61850 GOOSE uinteger 6
98B2 ...Repeated for IEC61850 GOOSE uinteger 7
98B5 ...Repeated for IEC61850 GOOSE uinteger 8
98B8 ...Repeated for IEC61850 GOOSE uinteger 9
98BB ...Repeated for IEC61850 GOOSE uinteger 10
98BE ...Repeated for IEC61850 GOOSE uinteger 11
98C1 ...Repeated for IEC61850 GOOSE uinteger 12
98C4 ...Repeated for IEC61850 GOOSE uinteger 13
98C7 ...Repeated for IEC61850 GOOSE uinteger 14
98CA ...Repeated for IEC61850 GOOSE uinteger 15
Table B–10: MODBUS MEMORY MAP (Sheet 44 of 68)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
