About reversing the door.
3
Loosen the bottom 2 right side hinge screws. Remove the
door and place it on a protected flat surface to avoid any
damage. Remove both the Blind Plate and the Strike
Plate and install them in opposite positions.
4
Remove the 4 door hinge screws, 4 edge screws, and 8
inside screws. Lift the inner door upwards using a flat
blade screwdriver.
Reversing the Door
Tools needed:
n Standard #2 Phillips screwdriver
n Tape-tipped putty knife
n Small flat blade screwdriver
Before you Start
Unplug the dryer from its electrical outlet.
1
Open the door approximately 170 degrees. With a putty
knife, remove the 4 plastic covers located along the left
side of the front panel and set them aside.
2
Remove the bottom screw from each hinge (right side)
and partially insert them into the top left side hinge
holes.
NOTE: All 4 front panel hinge screws will now be in the top
hinge holes - 2 on the left and 2 on the right.
Plastic Cover (4)
Left side of
front panel
12
Door hinge
screws
Inner door
Outer door
Inside screws
Inside screws
Edge
screws
Blind plate
Inner door
Strike plate
To Next Page
