2-2 6" QuickPanel* ViewBasic, Monochrome, Round Bezel – September 2010 GFK-2327B
2
QuickPanel View Hardware
Layout Diagram
In addition to the primary touch screen interface, the 6" QuickPanel View
supports an RS232/485 serial communications port for connection to a wide
variety of controllers. The back of the QuickPanel opens allowing access to the
DIP switches and battery. The following diagram shows the physical layout of
the QuickPanel View and the locations of ports and connections.
Caution
Remove power from the QuickPanel View before opening the
back. Working on a “live” unit may result in damage to
equipment and injury to personnel. Always use anti-static
precautions (i.e. grounded wrist strap) when accessing the
interior of the unit. Do not allow conductive material, liquid or
solid, to contact the electronics of the QuickPanel.
The left LED below the display is green when power is applied and amber if the
backlight fails;
the right LED is tricolor (green, red, or amber) and
programmable.
Note: Backlights are not field-replaceable.
