GFK-2327B Appendix A Specifications A-3
Display
Size 5.75" (14.6 cm) diagonal
Colors 256 shades of gray
Resolution 320 x 240
Fabrication Passive FSTN
Backlight Cold Cathode Fluorescent (CCFL) -rated half life: 50,000
hours.
Note: Backlight is not field replaceable.
Luminance 100 NITS
Front Panel
Bezel Material Valox 3706
For material specifications, visit
www.gepolymerland.com
Membrane Material Lexan HP60
For material specifications, visit geplastics.com
LEDs
Left Power status indicator (green with power applied, red if
either backlight fails)
Right Programmable tri-color (green, red, amber)
Touch Screen
Type Resistive, 12 bit
X axis: 320 cells
Y axis:240 cells
Resolution (after calibration)
(after calibration)
