20
Installation Instructions
REMOVE THE COVER
At the bottom rear of the refrigerator, remove the
screw(s) holding the compressor compartment
cover (if covered) and save for reinstallation later.
Bend the cover back for access to the compartment.
1
BEFORE YOU BEGIN
Read each step thoroughly before proceeding.
•
CAUTION
–
Unplug the
Refrigerator. To eliminate the danger
of electric shock during installation,
you must unplug the refrigerator from
its electrical outlet.
WATER VALVE ASSEMBLY INSTALLATION INSTRUCTIONS G
Are these the right instructions for your model? Follow the Installation Instructions indicated by
the label on the back of the refrigerator— or
RQPNMLKJHGFC
Flat blade and Phillips
screwdrivers
Pliers
TOOLS YOU WILL NEED
Sharp knife
1/4″ and 5/16″ Nutdrivers
ATTACH THE WATER VALVE
• Locate the female connector plug (B).
2
• Plug the female connector (B) onto the male
terminals on the water valve (4). Either wire
can go on either terminal.
• Fasten the water valve to the
cabinet edge hole
using the hex-head screw (13)
from the kit
.
DO NOT DRILL ANY ADDITIONAL HOLES.
• Check the plastic water line nut on the bottom of
the water valve to be sure it is hand tight. DO NOT
USE TOOLS.
B
B
4
13
To Next Page
