Installation Instructions
CONTENTS OF KIT IM-4
6
3
Owners Manual &
Installation Instructions
2
Ice Bucket
11
Water Line Clamp
(strain relief)
8
Water Line Clamp
12
Hex-Head Screw for Copper
Water Line Clamp
7
Water Valve and
Tube Assembly
4
Hose Clamp
(black)
Hose Clamp
(not black)
Hex-Head
Screw
13
Adhesive-Backed
Water Line Fasteners
5
15
Water Tube Inlet
14
Phillips Head
Screws (2)
Warranty Label
9
ICE MAKER
WARRANTY VERIFICATION
Date Installed
Dealer
Fill Tube Extension
(3/4″ O.D.)
10
21
18
Water Fill Tube
(5/8″ O.D.)
16
Hex-Head Screw (2)
17
Icemaker Bracket
25
Screws to Install
Bracket to Refrig.
Wall (3)
26
Icemaker Power Cord
Adapter (6 pin)
22
Icemaker Fill Cup
(center-mounted)
19
Icemaker Fill Cup
(side-mounted)
Icemaker Power Cord
Adapter (4 pin)
Plug Buttons (2)
27
Icemaker Insert
20
Water Valve
Wire Extension
23
Wire Ties (2)
24
Icemaker
1
Installation
Instructions
