Installation Instructions
Parts List Use with Installation Instructions:
C FGHJ K LMNPQ R
1 Icemaker XXXXXXXXXXXX
2 Owner’s Manual and XXXXXXXXXXXX
Installation Instructions
3 Hose Clamp (black) XXXXXXXXXX
4 Valve and Tube Assembly* XXXXXXXXXXXX
5 Adhesive-Backed Water Line Fasteners XXXXXXXXXXXX
6 Hose Clamp (not black) XXXXXXXXXXXX
7 Hex-Head Screw for Copper Water XX
Line Clamp
8 Water Line Clamp (strain relief) XXX XXXXXXX
9 Warranty Label XXXXXXXXXXXX
10 Fill Tube Extension (3/4″ O.D.) XXXXX XX XX
11 Ice Bucket XXXXXXXXXXX
12 Water Line Clamp (strain relief) X XXXXXXX X
13 Hex-Head Screw X XXXX
14 Phillips Head Screw (2) X X XXXXXX
15 Water Tube Inlet XXXXXXXXXX
16 Water Fill Tube (5/8″ O.D.) XXXXXXXXXX
17 Hex-Head Screw (2) X
18 Icemaker Fill Cup (side-mounted) XXXXX XXXXXX
19 Icemaker Fill Cup (center-mounted) X
20 Icemaker Insert X
21 Icemaker Power Cord Adapter (4 pin) XXXXX
22 Icemaker Power Cord Adapter (6 pin) XXXXXXX
23 Water Valve wire extension X
24 Wire Ties (2) XX
25 Icemaker Bracket X
26 Screws to Install Bracket to X
Refrigerator Wall (3)
27 Plug Buttons (2) XXXXXX
* Always change the water valve when replacing an icemaker that makes round cubes. This new
icemaker uses a different voltage which may cause the old valve to fail.
For dispenser models, order GE Part Number WR57X96.
