49-60704-2 9
INSTALLATION INSTRUCTIONS
Installation Instructions
REPOSITION OR REMOVE FREEZER SHELVES
On some models, you may need to remove or reposition the freezer shelf so the icemaker and bucket sit properly.
Follow the instructions below for the ice tray holder that looks like yours.
Type 1
• To reposition the two-piece shelf supports, slide
the shelf up off the base mount.
Base
mount
Shelf
support
Type 2
• On some bottom-mount no-frost refrigerators, you
need to remove a full width flat freezer shelf before
installing the icemaker.
To Next Page
