GE Multilin L30 Line Current Differential System 2-13
2 PRODUCT DESCRIPTION 2.2 ORDER CODES
2
B3 | | | | | | | | | IEEE 1588 and IEC 61850
B6 | | | | | | | | | IEEE 1588 and phasor measurement unit (PMU)
B7 | | | | | | | | | IEEE 1588 and IEC 61850 and phasor measurement unit (PMU)
BI | | | | | | | | | IEEE 1588 and three-pole autoreclose and synchrocheck
BJ | | | | | | | | | IEEE 1588 and three-pole autoreclose and synchrocheck and one PMU
BO | | | | | | | | | IEEE 1588 and In-zone transformer protection
BP | | | | | | | | | IEEE 1588 and IEC 61850 and In-zone transformer protection
BQ | | | | | | | | | IEEE 1588 and phasor measurement unit (PMU) and In-zone transformer protection
BR | | | | | | | | | IEEE 1588 and IEC 61850 and (PMU) and In-zone transformer protection
C0 | | | | | | | | | Parallel Redundancy Protocol (PRP)
C3 | | | | | | | | | PRP and IEC 61850
C6 | | | | | | | | | PRP and PMU
C7 | | | | | | | | | PRP, IEC 61850, and PMU
CI | | | | | | | | | PRP, three-pole autoreclose, synchrocheck
CJ | | | | | | | | | PRP, three-pole autoreclose, PMU, synchrocheck
CO | | | | | | | | | PRP and in-zone transformer protection
CP | | | | | | | | | PRP, in-zone transformer protection, and IEC 61850
CQ | | | | | | | | | PRP, in-zone transformer protection, and PMU
CR | | | | | | | | | PRP, in-zone transformer protection, IEC 61850, and PMU
D0 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1
D3 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850
D6 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and phasor measurement unit (PMU)
D7 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and phasor measurement unit (PMU)
DI | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and three-pole autoreclose and synchrocheck
DJ | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and three-pole autoreclose and synchrocheck and PMU
DO | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and In-zone transformer protection
DP | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and In-zone transformer protection
DQ | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and one PMU and In-zone transformer protection
DR | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and PMU and In-zone transformer protection
E0 | | | | | | | | | IEEE 1588 and PRP
E3 | | | | | | | | | IEEE 1588, PRP, IEC 61850
E6 | | | | | | | | | IEEE 1588, PRP, and PMU
E7 | | | | | | | | | IEEE 1588, PRP, IEC 61850, and PMU
EI | | | | | | | | | IEEE 1588, PRP, three-pole autoreclose, synchrocheck
EJ | | | | | | | | | IEEE 1588, PRP, three-pole autoreclose, PMU, synchrocheck
EO | | | | | | | | | IEEE 1588, PRP, and in-zone transformer protection
EP | | | | | | | | | IEEE 1588, PRP, in-zone transformer protection, and IEC 61850
EQ | | | | | | | | | IEEE 1588, PRP, in-zone transformer protection, and PMU
ER | | | | | | | | | IEEE 1588, PRP, in-zone transformer protection, IEC 61850, and PMU
F0 | | | | | | | | | PRP and CyberSentry Lvl 1
F3 | | | | | | | | | PRP, CyberSentry Lvl 1, and IEC 61850
F6 | | | | | | | | | PRP, CyberSentry Lvl 1, and PMU
F7 | | | | | | | | | PRP, CyberSentry Lvl 1, IEC 61850, and PMU
FI | | | | | | | | | PRP, CyberSentry Lvl 1, three-pole autoreclose, synchrocheck
FJ | | | | | | | | | PRP, CyberSentry Lvl 1, three-pole autoreclose, PMU, synchrocheck
FO | | | | | | | | | PRP, CyberSentry Lvl 1, in-zone transformer protection
FP | | | | | | | | | PRP, CyberSentry Lvl 1, in-zone transformer protection, and IEC 61850
FQ | | | | | | | | | PRP, CyberSentry Lvl 1, in-zone transformer protection, and PMU
FR | | | | | | | | | PRP, CyberSentry Lvl 1, in-zone transformer protection, IEC 61850, and PMU
G0 | | | | | | | | | IEEE 1588, PRP, and CyberSentry Lvl 1
G3 | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and IEC 61850
G6 | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, and PMU
G7 | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, IEC 61850, and PMU
GI | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, three-pole autoreclose, synchrocheck
GJ | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, three-pole autoreclose, PMU, synchrocheck
GO | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, in-zone transformer protection
GP | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, in-zone transformer protection, and IEC 61850
GQ | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, in-zone transformer protection, and PMU
GR | | | | | | | | | IEEE 1588, PRP, CyberSentry Lvl 1, in-zone transformer protection, IEC 61850, and PMU
J0 | | | | | | | | | IEC 60870-5-103
J3 | | | | | | | | | IEC 60870-5-103 + IEC 61850
J6 | | | | | | | | | IEC 60870-5-103 + PMU
J7 | | | | | | | | | IEC 60870-5-103 + IEC 61850 + PMU
JI | | | | | | | | | IEC 60870-5-103 + three-pole autoreclose + synchrocheck
JJ | | | | | | | | | IEC 60870-5-103 + three-pole autoreclose + PMU + synchrocheck
JO | | | | | | | | | IEC 60870-5-103 + in-zone transformer protection
JP | | | | | | | | | IEC 60870-5-103 + in-zone transformer protection + IEC 61850
JQ | | | | | | | | | IEC 60870-5-103 + in-zone transformer protection + PMU
JR | | | | | | | | | IEC 60870-5-103 + in-zone transformer protection + IEC 61850 + PMU
K0 | | | | | | | | | IEEE1588 + PRP + IEC 60870-5-103
K3 | | | | | | | | | IEEE1588 + PRP + IEC 60870-5-103 + IEC 61850
K6 | | | | | | | | | IEEE1588 + PRP + IEC 60870-5-103 + PMU
K7 | | | | | | | | | IEEE1588 + PRP + IEC 60870-5-103 + IEC 61850 + PMU
KI | | | | | | | | | IEEE1588 + PRP + IEC 60870-5-103 + three-pole autoreclose + synchrocheck
KJ | | | | | | | | | IEEE1588 + PRP + IEC 60870-5-103 + three-pole autoreclose + PMU + synchrocheck
KO | | | | | | | | | IEEE1588 + PRP + IEC 60870-5-103 + in-zone transformer protection
KP | | | | | | | | | IEEE1588 + PRP + IEC 60870-5-103 + in-zone transformer protection + IEC 61850
KQ | | | | | | | | | IEEE1588 + PRP + IEC 60870-5-103 + in-zone transformer protection + PMU
KR | | | | | | | | | IEEE1588 + PRP + IEC 60870-5-103 + in-zone transformer protection + IEC 61850 + PMU
L0 | | | | | | | | | IEC 60870-5-103 + IEEE1588 + PRP + CyberSentry Lvl 1 +
L3 | | | | | | | | | IEC 60870-5-103 + IEEE1588 + PRP + CyberSentry Lvl 1 + IEC 61850
L6 | | | | | | | | | IEC 60870-5-103 + IEEE1588 + PRP + CyberSentry Lvl 1 + PMU
L7 | | | | | | | | | IEC 60870-5-103 + IEEE1588 + PRP + CyberSentry Lvl 1 + IEC 61850 + PMU
LI|||||||| |
IEC 60870-5-103 + IEEE1588 + PRP + CyberSentry Lvl 1 + three-pole autoreclose +
synchrocheck
LJ|||||||| |
IEC 60870-5-103 + IEEE1588 + PRP + CyberSentry Lvl 1 + three-pole autoreclose + PMU +
synchrocheck
LO | | | | | | | | | IEC 60870-5-103 + IEEE1588 + PRP + CyberSentry Lvl 1 + in-zone transformer protection
LP|||||||| |
IEC 60870-5-103 + IEEE1588 + PRP + CyberSentry Lvl 1 + in-zone transformer protection + IEC
61850
LQ | | | | | | | | | IEC 60870-5-103 + IEEE1588 + PRP + CyberSentry Lvl 1 + in-zone transformer protection + PMU
LR|||||||| |
IEC 60870-5-103 + IEEE1588 + PRP + CyberSentry Lvl 1 + in-zone transformer protection + IEC
61850 + PMU
MOUNT/COATING H | | | | | | | | Horizontal (19” rack)
A | | | | | | | | Horizontal (19” rack) with harsh environmental coating
FACEPLATE/ DISPLAY C | | | | | | | English display
D | | | | | | | French display
R | | | | | | | Russian display
A | | | | | | | Chinese display
P | | | | | | | English display with 4 small and 12 large programmable pushbuttons
G | | | | | | | French display with 4 small and 12 large programmable pushbuttons
S | | | | | | | Russian display with 4 small and 12 large programmable pushbuttons
B | | | | | | | Chinese display with 4 small and 12 large programmable pushbuttons
K | | | | | | | Enhanced front panel with English display
M | | | | | | | Enhanced front panel with French display
Q | | | | | | | Enhanced front panel with Russian display
U | | | | | | | Enhanced front panel with Chinese display
L | | | | | | | Enhanced front panel with English display and user-programmable pushbuttons
N | | | | | | | Enhanced front panel with French display and user-programmable pushbuttons
T | | | | | | | Enhanced front panel with Russian display and user-programmable pushbuttons
V | | | | | | | Enhanced front panel with Chinese display and user-programmable pushbuttons
W | | | | | | | Enhanced front panel with Turkish display
Y | | | | | | | Enhanced front panel with Turkish display and user-programmable pushbuttons
I | | | | | | | Enhanced front panel with German display
J | | | | | | | Enhanced front panel with German display and user-programmable pushbuttons
POWER SUPPLY
(redundant supply must
be same type as main supply)
H | | | | | | 125 / 250 V AC/DC power supply
H | | | | | SH 125 / 250 V AC/DC with redundant 125 / 250 V AC/DC power supply
L | | | | | | 24 to 48 V (DC only) power supply
L | | | | | SL 24 to 48 V (DC only) with redundant 24 to 48 V DC power supply
PROCESS BUS MODULE | 81 | | | | Eight-port digital process bus module
DIGITAL INPUTS/OUTPUTS XX XX XX XX XX No Module
4A 4A | 4 Solid-State (no monitoring) MOSFET outputs
4B 4B | 4 Solid-State (voltage with optional current) MOSFET outputs
4C 4C | 4 Solid-State (current with optional voltage) MOSFET outputs
4D 4D | 16 digital inputs with Auto-Burnishing (maximum of three modules within a case)
4L 4L | 14 Form-A (no monitoring) Latching outputs
67 67 | 8 Form-A (no monitoring) outputs
Table 2–6: L30 ORDER CODES (HORIZONTAL UNITS WITH PROCESS BUS)
L30 - * ** - * * * - F ** - H ** - L ** - N ** - S ** - W/X ** Full Size Horizontal Mount
BASE UNIT L30 | | | | | | | | | | | Base Unit
