B-14 L30 Line Current Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
07E8 ...Repeated for IEC103 Command 27
07EC ...Repeated for IEC103 Command 28
07F0 ...Repeated for IEC103 Command 29
07F4 ...Repeated for IEC103 Command 30
07F8 ...Repeated for IEC103 Command 31
07FC ...Repeated for IEC103 Command 32
Digital Counter States Actual Values (Read Only Non-Volatile) (8 modules)
0800 Digital Counter 1 Value -2147483647 to
2147483647
--- 1 F004 0
0802 Digital Counter 1 Frozen -2147483647 to
2147483647
--- 1 F004 0
0804 Digital Counter 1 Frozen Time Stamp 0 to 4294967295 --- 1 F050 0
0806 Digital Counter 1 Frozen Time Stamp us (microsecond part
of time stamp)
0 to 4294967295 --- 1 F003 0
0808 ...Repeated for Digital Counter 2
0810 ...Repeated for Digital Counter 3
0818 ...Repeated for Digital Counter 4
0820 ...Repeated for Digital Counter 5
0828 ...Repeated for Digital Counter 6
0830 ...Repeated for Digital Counter 7
0838 ...Repeated for Digital Counter 8
FlexStates (Read Only)
0900 FlexState Bits (16 items) 0 to 65535 --- 1 F001 0
Element States (Read Only)
1000 Element Operate States (64 items) 0 to 65535 --- 1 F502 0
User Displays Actuals (Read Only)
1080 Formatted user-definable displays (16 items) --- --- --- F200 (none)
Modbus User Map Actuals (Read Only)
1200 User Map Values (256 items) 0 to 65535 --- 1 F001 0
Element Targets (Read Only)
14E0 Target Sequence 0 to 65535 --- 1 F001 0
14E1 Number of Targets 0 to 65535 --- 1 F001 0
Element Targets (Read/Write)
14E2 Target to Read 0 to 65535 --- 1 F001 0
Element Targets (Read Only)
14E3 Target Message --- --- --- F200 “.”
Contact Input/Output States (Read Only)
1500 Contact Input States (6 items) 0 to 65535 --- 1 F500 0
1508 Virtual Input States (8 items) 0 to 65535 --- 1 F500 0
1510 Contact Output States (4 items) 0 to 65535 --- 1 F500 0
1518 Contact Output Current States (4 items) 0 to 65535 --- 1 F500 0
1520 Contact Output Voltage States (4 items) 0 to 65535 --- 1 F500 0
1528 Virtual Output States (6 items) 0 to 65535 --- 1 F500 0
1530 Contact Output Detectors (4 items) 0 to 65535 --- 1 F500 0
Remote Input/Output States (Read Only)
1540 Remote Device States (2 items) 0 to 65535 --- 1 F500 0
1542 Remote Input States (4 items) 0 to 65535 --- 1 F500 0
1550 Remote Devices Online 0 to 1 --- 1 F126 0 (No)
1551 Remote Double-Point Status Input 1 State 0 to 3 --- 1 F605 3 (Bad)
1552 Remote Double-Point Status Input 2 State 0 to 3 --- 1 F605 3 (Bad)
1553 Remote Double-Point Status Input 3 State 0 to 3 --- 1 F605 3 (Bad)
1554 Remote Double-Point Status Input 4 State 0 to 3 --- 1 F605 3 (Bad)
1555 Remote Double-Point Status Input 5 State 0 to 3 --- 1 F605 3 (Bad)
Direct Input/Output States (Read Only)
15A0 Direct Input 1-1 State (8 items) 0 to 1 --- 1 F108 0 (Off)
Table B–10: MODBUS MEMORY MAP (Sheet 6 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
