GE L30

GE Multilin L30 Line Current Differential System B-15
APPENDIX B B.4 MEMORY MAPPING
B
15A8 Direct Input 1-2 State (8 items) 0 to 1 --- 1 F108 0 (Off)
15B0 Direct Input 1 State 0 to 65535 --- 1 F500 0
15B1 Direct Input 2 State 0 to 65535 --- 1 F500 0
Field Unit Input/Output States (Read Only)
15E0 Field Unit Contact Input States (3 items) 0 to 65535 --- 1 F500 0
15E3 Field Unit Contact Input Output Operand States (8 items) 0 to 65535 --- 1 F500 0
15EB Field Contact Output Physical States (8 items) 0 to 65535 --- 1 F500 0
15F3 Field Contact Output Current States (8 items) 0 to 65535 --- 1 F500 0
15FB Field Contact Output Physical States (8 items) 0 to 65535 --- 1 F500 0
1603 Field Shared Input States 0 to 65535 --- 1 F500 0
1604 Field Shared Input Channel States 0 to 65535 --- 1 F500 0
1605 Field Shared Input Test States 0 to 65535 --- 1 F500 0
1606 Field Shared Output Operand States 0 to 65535 --- 1 F500 0
1607 Field Latching Output Open Operand States 0 to 65535 --- 1 F500 0
1608 Field Latching Output Close Operand States 0 to 65535 --- 1 F500 0
1609 Field Latching Output Open Driver States 0 to 65535 --- 1 F500 0
160A Field Latching Output Close Driver States 0 to 65535 --- 1 F500 0
160B Field Latching Output Physical States 0 to 65535 --- 1 F500 0
160C Field Unit Online/Offline States 0 to 65535 --- 1 F500 0
160D Field RTD Input Trouble States 0 to 65535 --- 1 F500 0
160E Field Transducer Input Trouble States 0 to 65535 --- 1 F500 0
Ethernet Fibre Channel Status (Read Only)
1610 Ethernet Primary Fibre Channel Status 0 to 2 --- 1 F134 0 (Fail)
1611 Ethernet Secondary Fibre Channel Status 0 to 2 --- 1 F134 0 (Fail)
1612 Ethernet Tertiary Fibre Channel Status 0 to 2 --- 1 F134 0 (Fail)
Data Logger Actual Values (Read Only)
1618 Data Logger Channel Count 0 to 16 channel 1 F001 0
1619 Time of Oldest Available Samples 0 to 4294967295 seconds 1 F050 0
161B Time of Newest Available Samples 0 to 4294967295 seconds 1 F050 0
161D Data Logger Duration 0 to 999.9 days 0.1 F001 0
87L Channel Status Actual Values (Read Only)
1638 Channel 1 Asymmetry -65.535 to 65.535 ms 0.001 F004 0
163A Channel 2 Asymmetry -99.999 to 99.999 ms 0.001 F004 0
Field Unit RTD Actuals (Read Only) (8 modules)
16C0 Field RTD 1 Value -32768 to 32767 °C 1 F002 0
16C1 ...Repeated for Field RTD 2
16C2 ...Repeated for Field RTD 3
16C3 ...Repeated for Field RTD 4
16C4 ...Repeated for Field RTD 5
16C5 ...Repeated for Field RTD 6
16C6 ...Repeated for Field RTD 7
16C7 ...Repeated for Field RTD 8
Field Unit Transducer Actuals (Read Only) (8 modules)
16C8 Field Transducer 1 Value -32.768 to 32.767 --- 0.001 F004 0
16CA ...Repeated for Field Transducer 2
16CC ...Repeated for Field Transducer 3
16CE ...Repeated for Field Transducer 4
16D0 ...Repeated for Field Transducer 5
16D2 ...Repeated for Field Transducer 6
16D4 ...Repeated for Field Transducer 7
16D6 ...Repeated for Field Transducer 8
Source Current (Read Only) (2 modules)
1800 Source 1 Phase A Current RMS 0 to 999999.999 A 0.001 F060 0
1802 Source 1 Phase B Current RMS 0 to 999999.999 A 0.001 F060 0
Table B–10: MODBUS MEMORY MAP (Sheet 7 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
