B-24 L30 Line Current Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
34FC RTD Input 13 Value -32768 to 32767 °C 1 F002 0
34FD RTD Input 14 Value -32768 to 32767 °C 1 F002 0
34FE RTD Input 15 Value -32768 to 32767 °C 1 F002 0
34FF RTD Input 16 Value -32768 to 32767 °C 1 F002 0
3500 RTD Input 17 Value -32768 to 32767 °C 1 F002 0
3501 RTD Input 18 Value -32768 to 32767 °C 1 F002 0
3502 RTD Input 19 Value -32768 to 32767 °C 1 F002 0
3503 RTD Input 20 Value -32768 to 32767 °C 1 F002 0
3504 RTD Input 21 Value -32768 to 32767 °C 1 F002 0
3505 RTD Input 22 Value -32768 to 32767 °C 1 F002 0
3506 RTD Input 23 Value -32768 to 32767 °C 1 F002 0
3507 RTD Input 24 Value -32768 to 32767 °C 1 F002 0
3508 RTD Input 25 Value -32768 to 32767 °C 1 F002 0
3509 RTD Input 26 Value -32768 to 32767 °C 1 F002 0
350A RTD Input 27 Value -32768 to 32767 °C 1 F002 0
350B RTD Input 28 Value -32768 to 32767 °C 1 F002 0
350C RTD Input 29 Value -32768 to 32767 °C 1 F002 0
350D RTD Input 30 Value -32768 to 32767 °C 1 F002 0
350E RTD Input 31 Value -32768 to 32767 °C 1 F002 0
350F RTD Input 32 Value -32768 to 32767 °C 1 F002 0
3510 RTD Input 33 Value -32768 to 32767 °C 1 F002 0
3511 RTD Input 34 Value -32768 to 32767 °C 1 F002 0
3512 RTD Input 35 Value -32768 to 32767 °C 1 F002 0
3513 RTD Input 36 Value -32768 to 32767 °C 1 F002 0
3514 RTD Input 37 Value -32768 to 32767 °C 1 F002 0
3515 RTD Input 38 Value -32768 to 32767 °C 1 F002 0
3516 RTD Input 39 Value -32768 to 32767 °C 1 F002 0
3517 RTD Input 40 Value -32768 to 32767 °C 1 F002 0
3518 RTD Input 41 Value -32768 to 32767 °C 1 F002 0
3519 RTD Input 42 Value -32768 to 32767 °C 1 F002 0
351A RTD Input 43 Value -32768 to 32767 °C 1 F002 0
351B RTD Input 44 Value -32768 to 32767 °C 1 F002 0
351C RTD Input 45 Value -32768 to 32767 °C 1 F002 0
351D RTD Input 46 Value -32768 to 32767 °C 1 F002 0
351E RTD Input 47 Value -32768 to 32767 °C 1 F002 0
351F RTD Input 48 Value -32768 to 32767 °C 1 F002 0
Ohm Input Values (Read Only) (2 modules)
3520 Ohm Inputs 1 Value 0 to 65535 Ohm 1 F001 0
3521 Ohm Inputs 2 Value 0 to 65535 Ohm 1 F001 0
RADIUS Configuration (Read/Write Setting)
3735 Primary RADIUS IP Address 0 to 4294967295 --- 1 F003 0
3737 Primary Authentication Port 1 to 65535 --- 1 F001 1812
3738 Primary Accounting Port 1 to 65535 --- 1 F001 1813
3739 Secondary RADIUS IP Address 0 to 4294967295 --- 1 F003 0
373B Secondary Authentication Port 0 to 65535 --- 1 F001 1812
373D Secondary Accounting Port 0 to 65535 --- 1 F001 1813
373F RADIUS Authentication Method --- --- 1 F619 0 (EAP-TTLS)
3740 RADIUS Vendor ID 1 to 65535 --- 1 F001 2910
3741 Authentication Timeout 0 to 9999 sec 1 F001 10
3742 Authentication Retries 0 to 9999 --- 1 F001 3
3743 RADIUS Authentication Shared Secret --- --- --- F202 (none)
PTP Basic Configuration (Read/Write Setting)
3750 PTP Strict Power Profile 0 to 1 --- 1 F102 0 (Disabled)
3751 PTP Domain Number 0 to 255 --- 1 F001 0
Table B–10: MODBUS MEMORY MAP (Sheet 16 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
