GE Multilin L30 Line Current Differential System B-25
APPENDIX B B.4 MEMORY MAPPING
B
3752 PTP VLAN Priority 0 to 7 --- 1 F001 4
3753 PTP VLAN ID 0 to 4095 --- 1 F001 0
3754 Undefined (2 items) 0 to 1 --- 1 F001 0
PTP Port Configuration (Read/Write Setting) (3 modules)
3756 PTP Port 1 Function 0 to 1 --- 1 F102 0 (Disabled)
3757 PTP Port 1 Path Delay Adder 0 to 60000 ns 1 F001 0
3758 PTP Port 1 Path Delay Asymmetry -1000 to 1000 ns 1 F002 0
3759 ...Repeated for PTP Port 2
375C ...Repeated for PTP Port 3
Real Time Clock Synchronizing Actual Values (Read Only)
375F RTC Sync Source 0 to 5 --- 1 F624 0 (None)
3760 PTP GrandMaster ID 0 to 100 -- 1 F073 0
3764 Real Time Clock Accuracy 0 to 999999999 ns 1 F003 0
3766 PTP Port 1 State (3 items) 0 to 4 -- 1 F625 0 (Disabled)
3769 RTC Offset 0 to 999999999 ns 1 F004 0
376B PTP - IRIG-B Delta -500000000 to 500000000 ns 1 F004 0
Real Time Clock Synchronizing FlexAnalogs (Read Only)
376D PTP - IRIG-B Delta FlexAnalog -262143 to 262143 --- 1 F004 0
Field Units (Read/Write Setting) (8 modules)
3800 Field Unit 1 ID 0 to 1 --- 1 F205 "U1"
3806 Field Unit 1 Function 0 to 1 --- 1 F102 0 (Disabled)
3807 Field Unit 1 Type 0 to 3 --- 1 F243 0 (CC-05)
3808 Field Unit 1 Serial Number 1 to1 --- 1 F205 "000000000000"
380E Field Unit 1 Port 1 to 4 --- 1 F001 1
380F ...Repeated for Field Unit 2
381E ...Repeated for Filed Unit 3
382D ...Repeated for Filed Unit 4
383C ...Repeated for Filed Unit 5
384B ...Repeated for Filed Unit 6
385A ...Repeated for Filed Unit 7
3869 ...Repeated for Filed Unit 8
Field Unit Process Card Ports (Read/Write Setting)
3878 Field Unit 1 Process Card Port 0 to 7 --- 1 F244 6 (H1a)
3879 Field Unit 2 Process Card Port 0 to 7 --- 1 F244 4 (H2a)
387A Field Unit3 Process Card Port 0 to 7 --- 1 F244 2 (H3a)
387B Field Unit 4 Process Card Port 0 to 7 --- 1 F244 0 (H4a)
387C Field Unit 5 Process Card Port 0 to 7 --- 1 F244 7 (H1b)
387D Field Unit 6 Process Card Port 0 to 7 --- 1 F244 5 (H2b)
387E Field Unit 7 Process Card Port 0 to 7 --- 1 F244 3 (H3b)
387F Field Unit 8 Process Card Port 0 to 7 --- 1 F244 1 (H4b)
Field Unit CT VT Settings (Read/Write Setting) (6 modules)
3890 Remote Phase CT x Origin 1 0 to 16 --- 1 F247 0 (None)
3891 Remote Phase CT x Origin 2 0 to 16 --- 1 F247 0 (None)
3892 Remote Ground CT x Origin 1 0 to 16 --- 1 F248 0 (None)
3893 Remote Ground CT x Origin 2 0 to 16 --- 1 F248 0 (None)
3894 AC Bank Redundancy Type 0 to 2 --- 1 F261 1 (Dependability
Biased)
3895 Remote Phase CT 1 Primary 1 to 65000 --- 1 F001 1
3896 Remote Phase CT 1 Secondary 0 to 1 --- 1 F123 0 (1 A)
3897 Remote Ground CT 1 Primary 1 to 65000 --- 1 F001 1
3898 Remote Ground CT 1 Secondary 0 to 1 --- 1 F123 0 (1 A)
3899 Remote Phase VT 1 Connection 0 to 1 --- 1 F100 0 (Wye)
389A Remote Phase VT 1 Secondary 25 to 240 --- 0.1 F001 664
389B Remote Phase VT 1 Ratio 1 to 24000 --- 1 F060 1
Table B–10: MODBUS MEMORY MAP (Sheet 17 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
