GE Multilin L30 Line Current Differential System B-27
APPENDIX B B.4 MEMORY MAPPING
B
Field Unit Shared Inputs (Read/Write Setting) (16 modules)
3B00 Field Shared Input 1 ID 0 to 65535 --- 1 F205 "SI 1"
3B06 Field Shared Input 1 Unit Origin 1 0 to 8 --- 1 F256 0 (None)
3B07 Field Shared Input 1 Channel Origin 1 1 to 15 --- 1 F001 1
3B08 Field Shared Input 1 Events 0 to 1 --- 1 F102 1 (Enabled)
3B09 ...Repeated for Field Shared Input 2
3B12 ...Repeated for Field Shared Input 3
3B1B ...Repeated for Field Shared Input 4
3B24 ...Repeated for Field Shared Input 5
3B2D ...Repeated for Field Shared Input 6
3B36 ...Repeated for Field Shared Input 7
3B3F ...Repeated for Field Shared Input 8
3B48 ...Repeated for Field Shared Input 9
3B51 ...Repeated for Field Shared Input 10
3B5A ...Repeated for Field Shared Input 11
3B63 ...Repeated for Field Shared Input 12
3B6C ...Repeated for Field Shared Input 13
3B75 ...Repeated for Field Shared Input 14
3B7E ...Repeated for Field Shared Input 15
3B87 ...Repeated for Field Shared Input 16
Field Unit Contact Outputs (Read/Write Setting) (8 modules)
3B90 Field Contact Output 1 ID (6 items) --- --- --- F205 "FCO U /OUT"
3BB4 Field Output 1 Operate (6 items) 0 to 4294967295 --- 1 F300 0
3BC0 Field Output 1 Seal In (6 items) 0 to 4294967295 --- 1 F300 0
3BCC Field Output 1 Events (6 items) 0 to 1 --- 1 F102 1 (Enabled)
3BD2 ...Repeated for Field Contact Output 2
3C14 ...Repeated for Field Contact Output 3
3C56 ...Repeated for Field Contact Output 4
3C98 ...Repeated for Field Contact Output 5
3CDA ...Repeated for Field Contact Output 6
3D1C ...Repeated for Field Contact Output 7
3D5E ...Repeated for Field Contact Output 8
Field Unit Latching Outputs (Read/Write Setting) (8 modules)
3DC7 Field Latching Output 1 ID 0 to 1 --- 1 F205 "FLO Ux /LO"
3DCD Field Latching Output 1 Open 0 to 4294967295 --- 1 F300 0
3DCF Field Latching Output 1 Close 0 to 4294967295 --- 1 F300 0
3DD1 Field Latching Output 1 Events 0 to 1 --- 1 F102 1 (Enabled)
3DD2 Field Latching Output 1 Reserved (2 items) 0 to 1 --- 1 F001 0
3DD4 ...Repeated for Field Latching Output 2
3DE1 ...Repeated for Field Latching Output 3
3DEE ...Repeated for Field Latching Output 4
3DFB ...Repeated for Field Latching Output 5
3E08 ...Repeated for Field Latching Output 6
3E15 ...Repeated for Field Latching Output 7
3E22 ...Repeated for Field Latching Output 8
Field Unit Shared Outputs (Read/Write Setting) (16 modules)
3E30 Field Shared Output 1 ID 0 to 65535 --- 1 F205 "SO 1"
3E36 Field Shared Output 1 Operate 0 to 4294967295 --- 1 F300 0
3E38 Field Shared Output 1 Unit Dest 1 0 to 8 --- 1 F256 0 (None)
3E39 Field Shared Output 1 Channel Dest 1 1 to 15 --- 1 F001 1
3E3A Field Shared Output 1 Unit Dest 2 0 to 8 --- 1 F256 0 (None)
3E3B Field Shared Output 1 Channel Dest 2 1 to 15 --- 1 F001 1
3E3C Field Shared Output 1 Events 0 to 1 --- 1 F102 1 (Enabled)
3E3D ...Repeated for Field Shared Output 2
Table B–10: MODBUS MEMORY MAP (Sheet 19 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
