B.4 MEMORY MAPPING APPENDIX B
B
Stub Bus (Read/Write Grouped Setting)
5F10 Stub Bus Function 0 to 1 --- 1 F102 0 (Disabled)
5F11 Stub Bus Disconnect 0 to 4294967295 --- 1 F300 0
5F13 Stub Bus Trigger 0 to 4294967295 --- 1 F300 0
5F15 Stub Bus Target 0 to 2 --- 1 F109 0 (Self-reset)
5F17 Stub Bus Events 0 to 1 --- 1 F102 0 (Disabled)
50DD Disturbance Detection (Read/Write Grouped Setting)
5F20 50DD Function 0 to 1 --- 1 F102 0 (Disabled)
5F21 50DD Non Current Supervision 0 to 4294967295 --- 1 F300 0
5F23 50DD Control Logic 0 to 4294967295 --- 1 F300 0
5F25 50DD Logic Seal In 0 to 4294967295 --- 1 F300 0
5F27 50DD Events 0 to 1 --- 1 F102 0 (Disabled)
Setting Groups (Read/Write Setting)
5F70 Setting Group for Modbus Comms (0 means group 1) 0 to 5 --- 1 F001 0
5F71 Setting Groups Block 0 to 4294967295 --- 1 F300 0
5F73 FlexLogic Operands to Activate Groups 2 through 6 (5
items)
0 to 4294967295 --- 1 F300 0
5F7D Setting Group Function 0 to 1 --- 1 F102 0 (Disabled)
5F7E Setting Group Events 0 to 1 --- 1 F102 0 (Disabled)
Setting Groups (Read Only)
5F7F Current Setting Group 0 to 5 --- 1 F001 0
Setting Group Names (Read/Write Setting)
5F8C Setting Group 1 Name --- --- --- F203 (none)
5F94 Setting Group 2 Name --- --- --- F203 (none)
5F9C Setting Group 3 Name --- --- --- F203 (none)
5FA4 Setting Group 4 Name --- --- --- F203 (none)
5FAC Setting Group 5 Name --- --- --- F203 (none)
5FB4 Setting Group 6 Name --- --- --- F203 (none)
Current Differential 87L (Read/Write Grouped Setting)
6000 87L Current Differential Function 0 to 1 --- 1 F102 0 (Disabled)
6001 87L Current Differential Block 0 to 4294967295 --- 1 F300 0
6003 87L Current Differential Signal Source 1 0 to 5 --- 1 F167 0 (SRC 1)
6004 87L Minimum Phase Current Sensitivity 0.1 to 4 pu 0.01 F001 20
6005 87L Current Differential Tap Setting 0.2 to 5 --- 0.01 F001 100
6006 87L Current Differential Phase Percent Restraint 1 1 to 50 % 1 F001 30
6007 87L Current Differential Phase Percent Restraint 2 1 to 70 % 1 F001 50
6008 87L Current Differential Phase Dual Slope Breakpoint 0 to 20 pu 0.1 F001 10
6009 87L Current Differential Ground Function 0 to 1 --- 1 F102 0 (Disabled)
600A 87L Current Differential Ground Pickup 0.05 to 1 pu 0.01 F001 10
600B 87L Current Differential Ground Restraint 1 to 50 % 1 F001 25
600C 87L Current Differential Ground Delay 0 to 5 seconds 0.01 F001 10
600D 87L Current Differential Key DTT 0 to 1 --- 1 F102 1 (Enabled)
600E 87L Current Differential External Key DTT 0 to 4294967295 --- 1 F300 0
6010 87L Current Differential Target 0 to 2 --- 1 F109 0 (Self-reset)
6011 87L Current Differential Event 0 to 1 --- 1 F102 0 (Disabled)
6012 87L Current Differential Tap 2 Setting 0.2 to 5 --- 0.01 F001 100
Current Differential 87L In-Zone Transformer (Read/Write Grouped Setting)
601E 87L Inrush Inhibit Mode 0 to 3 --- 1 F561 0 (Disabled)
601F 87L Inrush Inhibit Level 1 to 40 %f
0
0.1 F001 200
Autoreclose (Read/Write Setting) (2 modules)
6200 Autoreclose 1 Function 0 to 1 --- 1 F102 0 (Disabled)
6201 Autoreclose 1 Initiate 0 to 4294967295 --- 1 F300 0
6203 Autoreclose 1 Block 0 to 4294967295 --- 1 F300 0
6205 Autoreclose 1 Max Number of Shots 1 to 4 --- 1 F001 1
Table B–10: MODBUS MEMORY MAP (Sheet 32 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
To Next Page
