GE Multilin L30 Line Current Differential System B-41
APPENDIX B B.4 MEMORY MAPPING
B
6206 Autoreclose 1 Manual Close 0 to 4294967295 --- 1 F300 0
6208 Autoreclose 1 Manual Reset from LO 0 to 4294967295 --- 1 F300 0
620A Autoreclose 1 Reset Lockout if Breaker Closed 0 to 1 --- 1 F108 0 (Off)
620B Autoreclose 1 Reset Lockout On Manual Close 0 to 1 --- 1 F108 0 (Off)
620C Autoreclose 1 Breaker Closed 0 to 4294967295 --- 1 F300 0
620E Autoreclose 1 Breaker Open 0 to 4294967295 --- 1 F300 0
6210 Autoreclose 1 Block Time Upon Manual Close 0 to 655.35 s 0.01 F001 1000
6211 Autoreclose 1 Dead Time Shot 1 0 to 655.35 s 0.01 F001 100
6212 Autoreclose 1 Dead Time Shot 2 0 to 655.35 s 0.01 F001 200
6213 Autoreclose 1 Dead Time Shot 3 0 to 655.35 s 0.01 F001 300
6214 Autoreclose 1 Dead Time Shot 4 0 to 655.35 s 0.01 F001 400
6215 Autoreclose 1 Reset Lockout Delay 0 to 655.35 s 0.01 F001 6000
6216 Autoreclose 1 Reset Time 0 to 655.35 s 0.01 F001 6000
6217 Autoreclose 1 Incomplete Sequence Time 0 to 655.35 s 0.01 F001 500
6218 Autoreclose 1 Events 0 to 1 --- 1 F102 0 (Disabled)
6219 Autoreclose 1 Reduce Max 1 0 to 4294967295 --- 1 F300 0
621B Autoreclose 1 Reduce Max 2 0 to 4294967295 --- 1 F300 0
621D Autoreclose 1 Reduce Max 3 0 to 4294967295 --- 1 F300 0
621F Autoreclose 1 Add Delay 1 0 to 4294967295 --- 1 F300 0
6221 Autoreclose 1 Delay 1 0 to 655.35 s 0.01 F001 0
6222 Autoreclose 1 Add Delay 2 0 to 4294967295 --- 1 F300 0
6224 Autoreclose 1 Delay 2 0 to 655.35 s 0.01 F001 0
6225 Reserved (4 items) 0 to 0.001 --- 0.001 F001 0
6229 ...Repeated for Autoreclose 2
Negative Sequence Time Overcurrent (Read/Write Grouped Setting) (2 modules)
6300 Negative Sequence Time Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
6301 Negative Sequence Time Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
6302 Negative Sequence Time Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
6303 Negative Sequence Time Overcurrent 1 Curve 0 to 16 --- 1 F103 0 (IEEE Mod Inv)
6304 Negative Sequence Time Overcurrent 1 Multiplier 0 to 600 --- 0.01 F001 100
6305 Negative Sequence Time Overcurrent 1 Reset 0 to 1 --- 1 F104 0 (Instantaneous)
6306 Negative Sequence Time Overcurrent 1 Block 0 to 4294967295 --- 1 F300 0
6308 Negative Sequence Time Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
6309 Negative Sequence Time Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
630A Reserved (7 items) 0 to 1 --- 1 F001 0
6311 ...Repeated for Negative Sequence Time Overcurrent 2
Negative Sequence Instantaneous Overcurrent (Read/Write Grouped Setting) (2 modules)
63C0 Negative Sequence Instantaneous OC 1 Function 0 to 1 --- 1 F102 0 (Disabled)
63C1 Negative Sequence Instantaneous OC 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
63C2 Negative Sequence Instantaneous Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
63C3 Negative Sequence Instantaneous Overcurrent 1 Delay 0 to 600 s 0.01 F001 0
63C4 Negative Sequence Instantaneous OC 1 Reset Delay 0 to 600 s 0.01 F001 0
63C5 Negative Sequence Instantaneous Overcurrent 1 Block 0 to 4294967295 --- 1 F300 0
63C7 Negative Sequence Instantaneous Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
63C8 Negative Sequence Instantaneous Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
63C9 Reserved (8 items) 0 to 1 --- 1 F001 0
63D1 ...Repeated for Negative Sequence Instantaneous OC 2
Negative Sequence Overvoltage (Read/Write Grouped Setting) (3 modules)
6440 Negative Sequence Overvoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
6441 Negative Sequence Overvoltage 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
6442 Negative Sequence Overvoltage 1 Pickup 0 to 1.25 pu 0.001 F001 300
6443 Negative Sequence Overvoltage 1 Pickup Delay 0 to 600 s 0.01 F001 50
6444 Negative Sequence Overvoltage 1 Reset Delay 0 to 600 s 0.01 F001 50
6445 Negative Sequence Overvoltage 1 Block 0 to 4294967295 --- 1 F300 0
Table B–10: MODBUS MEMORY MAP (Sheet 33 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
