GE Multilin L30 Line Current Differential System B-45
APPENDIX B B.4 MEMORY MAPPING
B
7A84 Underfrequency 1 Pickup 20 to 65 Hz 0.01 F001 5950
7A85 Underfrequency 1 Pickup Delay 0 to 65.535 s 0.001 F001 2000
7A86 Underfrequency 1 Reset Delay 0 to 65.535 s 0.001 F001 2000
7A87 Underfrequency 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
7A88 Underfrequency 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7A89 Underfrequency 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7A8A Underfrequency 1 Reserved (5 items) 0 to 1 --- 1 F001 0
7A8F ...Repeated for Underfrequency 2
7A9E ...Repeated for Underfrequency 3
7AAD ...Repeated for Underfrequency 4
7ABC ...Repeated for Underfrequency 5
7ACB ...Repeated for Underfrequency 6
User Programmable Pushbuttons (Read/Write Setting) (16 modules)
7B60 User Programmable Pushbutton 1 Function 0 to 2 --- 1 F137 0 (Disabled)
7B61 User Programmable Pushbutton 1 Top Line --- --- --- F202 (none)
7B6B User Programmable Pushbutton 1 On Text --- --- --- F202 (none)
7B75 User Programmable Pushbutton 1 Off Text --- --- --- F202 (none)
7B7F User Programmable Pushbutton 1 Drop-Out Time 0 to 60 s 0.05 F001 0
7B80 User Programmable Pushbutton 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7B81 User Programmable Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7B82 User Programmable Pushbutton 1 LED Operand 0 to 4294967295 --- 1 F300 0
7B84 User Programmable Pushbutton 1 Autoreset Delay 0.2 to 600 s 0.1 F001 10
7B85 User Programmable Pushbutton 1 Autoreset Function 0 to 1 --- 1 F102 0 (Disabled)
7B86 User Programmable Pushbutton 1 Local Lock Operand 0 to 4294967295 --- 1 F300 0
7B88 User Programmable Pushbutton 1 Message Priority 0 to 2 --- 1 F220 0 (Disabled)
7B89 User Programmable Pushbutton 1 Remote Lock Operand 0 to 4294967295 --- 1 F300 0
7B8B User Programmable Pushbutton 1 Reset Operand 0 to 4294967295 --- 1 F300 0
7B8D User Programmable Pushbutton 1 Set Operand 0 to 4294967295 --- 1 F300 0
7B8F User Programmable Pushbutton 1 Hold 0 to 10 s 0.1 F001 1
7B90 ...Repeated for User Programmable Pushbutton 2
7BC0 ...Repeated for User Programmable Pushbutton 3
7BF0 ...Repeated for User Programmable Pushbutton 4
7C20 ...Repeated for User Programmable Pushbutton 5
7C50 ...Repeated for User Programmable Pushbutton 6
7C80 ...Repeated for User Programmable Pushbutton 7
7CB0 ...Repeated for User Programmable Pushbutton 8
7DE0 ...Repeated for User Programmable Pushbutton 9
7D10 ...Repeated for User Programmable Pushbutton 10
7D40 ...Repeated for User Programmable Pushbutton 11
7D70 ...Repeated for User Programmable Pushbutton 12
7DA0 ...Repeated for User Programmable Pushbutton 13
7DD0 ...Repeated for User Programmable Pushbutton 14
7E00 ...Repeated for User Programmable Pushbutton 15
7E30 ...Repeated for User Programmable Pushbutton 16
Auxiliary Undervoltage (Read/Write Grouped Setting
7F60 Auxiliary Undervoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7F61 Auxiliary Undervoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7F62 Auxiliary Undervoltage 1 Pickup 0 to 3 pu 0.001 F001 700
7F63 Auxiliary Undervoltage 1 Delay 0 to 600 s 0.01 F001 100
7F64 Auxiliary Undervoltage 1 Curve 0 to 1 --- 1 F111 0 (Definite Time)
7F65 Auxiliary Undervoltage 1 Minimum Voltage 0 to 3 pu 0.001 F001 100
7F66 Auxiliary Undervoltage 1 Block 0 to 4294967295 --- 1 F300 0
7F68 Auxiliary Undervoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7F69 Auxiliary Undervoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
Table B–10: MODBUS MEMORY MAP (Sheet 37 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
