B-50 L30 Line Current Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
98BB ...Repeated for IEC61850 GOOSE uinteger 10
98BE ...Repeated for IEC61850 GOOSE uinteger 11
98C1 ...Repeated for IEC61850 GOOSE uinteger 12
98C4 ...Repeated for IEC61850 GOOSE uinteger 13
98C7 ...Repeated for IEC61850 GOOSE uinteger 14
98CA ...Repeated for IEC61850 GOOSE uinteger 15
98CD ...Repeated for IEC61850 GOOSE uinteger 16
FlexElement Actual Values (Read Only) (8 modules)
9900 FlexElement 1 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9902 FlexElement 2 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9904 FlexElement 3 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9906 FlexElement 4 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9908 FlexElement 5 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
990A FlexElement 6 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
990C FlexElement 7 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
990E FlexElement 8 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
VT Fuse Failure (Read/Write Setting) (2 modules)
A09A VT Fuse Failure1 Function 0 to 1 --- 1 F102 0 (Disabled)
A09B VT Fuse Failure Neutral Wire Open1 Function 0 to 1 --- 1 F102 0 (Disabled)
A09C VT Fuse Failure Neutral Wire Open 1 3rd Harmonic Pickup 0 to 3 pu 0.001 F001 100
A09D ...Repeated for module number 2
VT Fuse Failure Actuals (Read Only) (2 modules)
A0AC VT Fuse Failure 1 V0 3rd Harmonic 0 to 999999.999 V 0.001 F060 0
A0AE ...Repeated for module number 2
Selector Switch Actual Values (Read Only)
A210 Selector Switch 1 Position 1 to 7 --- 1 F001 0
A211 Selector Switch 2 Position 1 to 7 --- 1 F001 1
Selector Switch Settings (Read/Write) (2 modules)
A280 Selector 1 Function 0 to 1 --- 1 F102 0 (Disabled)
A281 Selector 1 Range 1 to 7 --- 1 F001 7
A282 Selector 1 Timeout 3 to 60 s 0.1 F001 50
A283 Selector 1 Step Up 0 to 4294967295 --- 1 F300 0
A285 Selector 1 Step Mode 0 to 1 --- 1 F083 0 (Time-out)
A286 Selector 1 Acknowledge 0 to 4294967295 --- 1 F300 0
A288 Selector 1 Bit0 0 to 4294967295 --- 1 F300 0
A28A Selector 1 Bit1 0 to 4294967295 --- 1 F300 0
A28C Selector 1 Bit2 0 to 4294967295 --- 1 F300 0
A28E Selector 1 Bit Mode 0 to 1 --- 1 F083 0 (Time-out)
A28F Selector 1 Bit Acknowledge 0 to 4294967295 --- 1 F300 0
A291 Selector 1 Power Up Mode 0 to 2 --- 1 F084 0 (Restore)
A292 Selector 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
A293 Selector 1 Events 0 to 1 --- 1 F102 0 (Disabled)
A294 Reserved (10 items) --- --- 1 F001 0
A29E ...Repeated for Selector 2
Digital Counter (Read/Write Setting) (8 modules)
A300 Digital Counter 1 Function 0 to 1 --- 1 F102 0 (Disabled)
A301 Digital Counter 1 Name --- --- --- F205 “Counter 1"
A307 Digital Counter 1 Units --- --- --- F206 (none)
A30A Digital Counter 1 Block 0 to 4294967295 --- 1 F300 0
A30C Digital Counter 1 Up 0 to 4294967295 --- 1 F300 0
A30E Digital Counter 1 Down 0 to 4294967295 --- 1 F300 0
A311 Digital Counter 1 Preset –2147483647 to
2147483647
--- 1 F004 0
A313 Digital Counter 1 Compare –2147483647 to
2147483647
--- 1 F004 0
Table B–10: MODBUS MEMORY MAP (Sheet 42 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
