GE Multilin L30 Line Current Differential System B-51
APPENDIX B B.4 MEMORY MAPPING
B
A315 Digital Counter 1 Reset 0 to 4294967295 --- 1 F300 0
A317 Digital Counter 1 Freeze/Reset 0 to 4294967295 --- 1 F300 0
A319 Digital Counter 1 Freeze/Count 0 to 4294967295 --- 1 F300 0
A31B Digital Counter 1 Set To Preset 0 to 4294967295 --- 1 F300 0
A31D Reserved (11 items) --- --- --- F001 0
A328 ...Repeated for Digital Counter 2
A350 ...Repeated for Digital Counter 3
A378 ...Repeated for Digital Counter 4
A3A0 ...Repeated for Digital Counter 5
A3C8 ...Repeated for Digital Counter 6
A3F0 ...Repeated for Digital Counter 7
A418 ...Repeated for Digital Counter 8
FlexCurves C and D (Read/Write Setting)
A600 FlexCurve C (120 items) 0 to 65535 ms 1 F011 0
A680 FlexCurve D (120 items) 0 to 65535 ms 1 F011 0
Non Volatile Latches (Read/Write Setting) (16 modules)
A700 Non-Volatile Latch 1 Function 0 to 1 --- 1 F102 0 (Disabled)
A701 Non-Volatile Latch 1 Type 0 to 1 --- 1 F519 0 (Reset
Dominant)
A702 Non-Volatile Latch 1 Set 0 to 4294967295 --- 1 F300 0
A704 Non-Volatile Latch 1 Reset 0 to 4294967295 --- 1 F300 0
A706 Non-Volatile Latch 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
A707 Non-Volatile Latch 1 Events 0 to 1 --- 1 F102 0 (Disabled)
A708 Reserved (4 items) --- --- --- F001 0
A70C ...Repeated for Non-Volatile Latch 2
A718 ...Repeated for Non-Volatile Latch 3
A724 ...Repeated for Non-Volatile Latch 4
A730 ...Repeated for Non-Volatile Latch 5
A73C ...Repeated for Non-Volatile Latch 6
A748 ...Repeated for Non-Volatile Latch 7
A754 ...Repeated for Non-Volatile Latch 8
A760 ...Repeated for Non-Volatile Latch 9
A76C ...Repeated for Non-Volatile Latch 10
A778 ...Repeated for Non-Volatile Latch 11
A784 ...Repeated for Non-Volatile Latch 12
A790 ...Repeated for Non-Volatile Latch 13
A79C ...Repeated for Non-Volatile Latch 14
A7A8 ...Repeated for Non-Volatile Latch 15
A7B4 ...Repeated for Non-Volatile Latch 16
IEC 61850 Received Analog Settings (Read/Write Setting) (32 modules)
AA00 IEC 61850 GOOSE Analog 1 Default Value –1000000 to 1000000 --- 0.001 F060 1000
AA02 IEC 61850 GOOSE Analog Input 1 Mode 0 to 1 --- 1 F491 0 (Default Value)
AA03 IEC 61850 GOOSE Analog Input 1 Units --- --- --- F207 (none)
AA05 IEC 61850 GOOSE Analog Input 1 Per-Unit Base 0 to 999999999.999 --- 0.001 F060 1
AA07 ...Repeated for IEC 61850 GOOSE Analog Input 2
AA0E ...Repeated for IEC 61850 GOOSE Analog Input 3
AA15 ...Repeated for IEC 61850 GOOSE Analog Input 4
AA1C ...Repeated for IEC 61850 GOOSE Analog Input 5
AA23 ...Repeated for IEC 61850 GOOSE Analog Input 6
AA2A ...Repeated for IEC 61850 GOOSE Analog Input 7
AA31 ...Repeated for IEC 61850 GOOSE Analog Input 8
AA38 ...Repeated for IEC 61850 GOOSE Analog Input 9
AA3F ...Repeated for IEC 61850 GOOSE Analog Input 10
AA46 ...Repeated for IEC 61850 GOOSE Analog Input 11
Table B–10: MODBUS MEMORY MAP (Sheet 43 of 63)
